基于合成孔径雷达数据的农作物长势监测研究进展

doi:10.12133/j.smartag.SA202308019

摘要/Abstract

摘要：

目的/意义 农作物长势监测能及时提供农作物的生长状态信息，对于加强中国作物生产管理、确保国家粮食安全具有重要的意义。卫星遥感技术的发展为大面积的作物长势监测提供了契机。然而，在雨热同期的作物生长旺季，光学遥感数据的获取经常受到天气的限制。因此，近年微波雷达遥感技术受到了广泛重视。［进展］梳理了利用合成孔径雷达（Synthetic Aperture Radar, SAR）数据进行农作物长势监测的国内外研究现状，从农作物长势SAR遥感监测指标、农作物长势SAR遥感监测数据和农作物长势SAR遥感监测方法3个方面对基于SAR数据农作物长势监测研究进展与标志性成果进行总结。在分析常用于农作物长势监测的方法及其适用性的基础上，对它们在长势监测中应用情况进行分析。［结论/展望］提出了4个国内外SAR监测农作物长势所存在的问题：1）基于SAR数据的农作物长势监测方法研究整体较少；2）微波散射特征挖掘不够，特别是对极化分解参数的长势监测应用研究还有待深入；3）针对农作物长势监测中的雷达植被指数相对较少，其应用尚未得到充分发挥；4）基于SAR散射强度的农作物长势监测主要采用经验模型，难以推广到不同地区和类型的农作物上。最后，展望未来的研究应聚焦于挖掘微波散射特征、利用SAR极化分解参数、发展和优化雷达植被指数以及深化散射模型来监测农作物长势。

关键词: 长势监测, 合成孔径雷达, 雷达植被指数, 机理模型法

Abstract:

Significance Crop production is related to national food security, economic development and social stability, so timely information on the growth of major crops is of great significance for strengthening the crop production management and ensuring food security. The traditional crop growth monitoring mainly judges the growth of crops by manually observing the shape, color and other appearance characteristics of crops through the external industry, which has better reliability and authenticity, but it will consume a lot of manpower, is inefficient and difficult to carry out monitoring of a large area. With the development of space technology, satellite remote sensing technology provides an opportunity for large area crop growth monitoring. However, the acquisition of optical remote sensing data is often limited by the weather during the peak crop growth season when rain and heat coincide. Synthetic aperture radar (SAR) compensates well for the shortcomings of optical remote sensing, and has a wide demand and great potential for application in crop growth monitoring. However, the current research on crop growth monitoring using SAR data is still relatively small and lacks systematic sorting and summarization. In this paper, the research progress of SAR inversion of crop growth parameters were summarized through comprehensive analysis of existing literature, clarify the main technical methods and application of SAR monitoring of crop growth, and explore the existing problems and look forward to its future research direction. Progress] The current research status of SAR crop growth monitoring were reviewed, the application of SAR technology had gone through several development stages: from the early single-polarization, single-band stage, gradually evolving to the mid-term multi-polarization, multi-band stage, and then to the stage of joint application of tight polarization and optical remote sensing. Then, the research progress and milestone achievements of crop growth monitoring based on SAR data were summarized in three aspects, namely, crop growth SAR remote sensing monitoring indexes, crop growth SAR remote sensing monitoring data and crop growth SAR remote sensing monitoring methods. First, the key parameters of crop growth were summarized, and the crop growth monitoring indexes were divided into morphological indicators, physiological and biochemical indicators, yield indicators and stress indicators. Secondly, the core principle of SAR monitoring of crop growth parameters was introduced, which was based on the interaction between SAR signals and vegetation, and then the specific scattering model and inversion algorithm were used to estimate the crop growth parameters. Then, a detailed summary and analysis of the radar indicators mainly applied to crop growth monitoring were also presented. Finally, SAR remote sensing methods for crop growth monitoring, including mechanistic modeling, empirical modeling, semi-empirical modeling, direct monitoring, and assimilation monitoring of crop growth models, were described, and their applicability and applications in growth monitoring were analyzed. Conclusions and Prospects Four challenges exist in SAR crop growth monitoring are proposed: 1) Compared with the methods of crop growth monitoring using optical remote sensing data, the methods of crop growth monitoring using SAR data are obviously relatively small. The reason may be that SAR remote sensing itself has some inherent shortcomings; 2) Insufficient mining of microwave scattering characteristics, at present, a large number of studies have applied the backward scattering intensity and polarization characteristics to crop growth monitoring, but few have applied the phase information to crop growth monitoring, especially the application study of polarization decomposition parameters to growth monitoring. The research on the application of polarization decomposition parameter to crop growth monitoring is still to be deepened; 3) Compared with the optical vegetation index, the radar vegetation index applied to crop growth monitoring is relatively less; 4 ) Crop growth monitoring based on SAR scattered intensity is mainly based on an empirical model, which is difficult to be extended to different regions and types of crops, and the existence of this limitation prevents the SAR scattering intensity-based technology from effectively realizing its potential in crop growth monitoring. Finally, future research should focus on mining microwave scattering features, utilizing SAR polarization decomposition parameters, developing and optimizing radar vegetation indices, and deepening scattering models for crop growth monitoring.

Key words: growth monitoring, synthetic aperture radar (SAR), radar vegetation index, mechanistic modeling method

洪玉娇, 张硕, 李俐. 基于合成孔径雷达数据的农作物长势监测研究进展[J]. 智慧农业(中英文), 2024, 6(1): 46-62.

HONG Yujiao, ZHANG Shuo, LI Li. Research Progresses of Crop Growth Monitoring Based on Synthetic Aperture Radar Data[J]. Smart Agriculture, 2024, 6(1): 46-62.

图/表 6

表1

表2

主要雷达指标及应用特性

类型	SAR参数	应用特性
H/A/ $α ¯$ 分解	散射熵Entropy（H）^{［73， 74］}	H的取值范围为［0，1］，代表散射随机性的大小，H越小表示散射随机程度越低；H对植物的茎高有较高的敏感性
	反熵Anisotropy（A）^［75］	A反映了Cloude分解中 $λ$ ₂和λ ₃对应的两种散射机制的关系；当A较小时，λ ₃所对应的散射机制会影响散射结果；而当A较大时， $λ$ ₂所对应的散射机制对散射结果产生影响；A对作物的物候期变化最为敏感
	散射角Alpha（ $α$ ）^［76］	$α$ 取值范围为［0°， 90°］，其和目标的散射机理相关。当 $α$ =0°时，目标为平面散射；当 $α$ =45°时，目标为体散射；当 $α$ =90°时，目标为偶次散射，与H相似， $α$ 也对作物的茎高敏感
极化特征参数	特征值λ^［77］	λ是通过对相干矩阵进行分解获得的，其大小和分布可以提供有关信号的极化特性和目标散射特性的信息，适用于对作物的健康监测
	香农熵Shannon Entropy （SE）^{［78， 79］}	将SE引入极化雷达应用中，有助于测量地物目标散射的信息量，同时反映了地物目标散射的随机性，可以准确反映作物的散射特征
	相干矩阵主对角线元素（S _HH、S _VV）^［77］	S _HH、S _VV通常用来描述SAR接收到的极化信号的功率，可以用来追踪作物的健康状况变化；健康的作物有较高的极化信号率，而有疾病或营养不良的作物则有较低的极化信号功率
	基高Base Height^［80］	基高参数在极化SAR中是一个关键参数，可以用于监测不同作物的生长情况；不同类型的作物在生长期间会有不同的高度变化，通过基高参数的变化，可以追踪作物的生长进程，识别作物类型并评估其生长状况
散射强度特征指数	VV-HV、HH-HV、HH-VV、HH/VV、VH/VV、HH+HV、HH+VV、VV+VH^{［20， 81-83］}	VV和HH为同极化，VV表示SAR接收和发射的信号都为垂直分量，HH表示SAR接收和发射的信号都为水平分量；HV和VH都为交叉极化，HV表示SAR发射的是水平信号，接收的反射信号为垂直信号，VH则与HV相反；通过加减乘除构建散射强度特征指数，可以突出作物的特征。例如，VV-VH对玉米冠层很敏感，HH/VV对小麦LAI敏感
植被指数	Radar Vegetation Index （ $R V I K i m$ ）^［84］	$R V I K i m = 8 σ H V 0 σ H H 0 + σ V V 0 + 2 σ H V 0 (1), 0 ≤ R V I K i m ≤ 1, R V I K i m$ 用于全极化SAR数据，是散射随机性的度量，对植被生物量与介电特性敏感
	Radar Vegetation Index （ $R V I V V$ ）^［85］	$R V I V V = 4 σ V H 0 σ V V 0 + σ V H 0 (2), 0 ≤ R V I V V ≤ 1$ ， $R V I V V$ 是对 $R V I K i m$ 的改进，用于双极化数据（VV与VH），是体散射的度量，当体散射为主要散射机制时其与 $R V I K i m$ 差异很小，适用于农作物监测
	Dual Polarimetric Radar Vegetation Index （ $D p R V I$ ）^［86］	$D p R V I = 1 - m β (3), 0 ≤ D p R V I ≤ 1$ ， $m = 1 - 4 C 2 (T r (C 2)) 2$ $(4)$ ； $D p R V I$ 对植被形态结构和介电特性敏感，与植被含水量、种植面积和干生物量相关性高，适用于大区域农作物长势监测以及作物生物物理参数的反演
	Generalized Radar Vegetion Index（GRVI）^［87］	$G R V I = β f V (5), 0 ≤ G R V I ≤ 1$ ， $f V = 1 - G D V (6), β = (p q) 2 G D V (7)$ ， $p = m i n G D K, K t G D K, K c G D K, K d G D K, K n d 8, q = m a x G D K, K t G D K, K c G D K, K d G D K, K n d (9)$ ； GRVI对植被形态结构和介电特性敏感，与植被含水量和植物面积指数相关性好，适用于农作物长势监测以及作物生物物理参数的反演
	Compact-pol Radar Vegetation Index（CpRVI）^［88］	$C p R V I = β f I D (10), 0 ≤ C p R V I ≤ 1$ ， $β = (p q) 2 (3 / 2 G D I D) (11)$ ， $p = m i n S C, O C 12, q = m a x S C, O C (13)$ ，CpRVI是对GRVI的改进，用于紧致极化合成孔径雷达（CP-SAR），其对植被介电特性和冠层结构，适用于农作物长势监测，但性能弱于GRVI

表2

图1

图2

图3

图4

参考文献 139

1	杨邦杰, 裴志远. 农作物长势的定义与遥感监测[J]. 农业工程学报, 1999, 15(3): 214-218.
	YANG B J, PEI Z Y. Definition of crop condition and crop monitoring using remote sensing[J]. Transactions of the Chinese society of agricultural engineering, 1999, 15(3): 214-218.
2	王翔宇, 杨菡, 李鑫星, 等. 基于无人机可见光谱遥感的玉米长势监测[J]. 光谱学与光谱分析, 2021, 41(1): 265-270.
	WANG X Y, YANG H, LI X X, et al. Research on maize growth monitoring based on visible spectrum of UAV remote sensing[J]. Spectroscopy and spectral analysis, 2021, 41(1): 265-270.
3	王蕾, 王鹏新, 李俐, 等. 河北省中部平原玉米长势遥感综合监测[J]. 资源科学, 2018, 40(10): 2099-2109.
	WANG L, WANG P X, LI L, et al. Integrated maize growth monitoring based on gray correlation analysis and remote sense data in the central plain of Hebei province[J]. Resources science, 2018, 40(10): 2099-2109.
4	魏青, 张宝忠, 魏征, 等. 基于无人机多光谱遥感的冬小麦冠层叶绿素含量估测研究[J]. 麦类作物学报, 2020, 40(3): 365-372.
	WEI Q, ZHANG B Z, WEI Z, et al. Estimation of canopy chlorophyll content in winter wheat by UAV multispectral remote sensing[J]. Journal of triticeae crops, 2020, 40(3): 365-372.
5	李平湘, 赵伶俐, 任烨仙. 合成孔径雷达在农业监测中的应用和展望[J]. 地理空间信息, 2017, 15(3): 1-4, 10.
	LI P X, ZHAO L L, REN Y X. Outlook and application of the synthetic aperture radar in agriculture monitoring[J]. Geospatial information, 2017, 15(3): 1-4, 10.
6	HOSSEINI M, MCNAIRN H. Using multi-polarization C- and L-band synthetic aperture radar to estimate biomass and soil moisture of wheat fields[J]. International journal of applied earth observation and geoinformation, 2017, 58: 50-64.
7	陈仲新, 郝鹏宇, 刘佳, 等. 农业遥感卫星发展现状及中国监测需求分析[J]. 智慧农业, 2019, 1(1): 32-42.
	CHEN Z X, HAO P Y, LIU J, et al. Technical demands for agricultural remote sensing satellites in China[J]. Smart agriculture, 2019, 1(1): 32-42.
8	陈仲新, 任建强, 唐华俊, 等. 农业遥感研究应用进展与展望[J]. 遥感学报, 2016, 20(5): 748-767.
	CHEN Z X, REN J Q, TANG H J, et al. Progress and perspectives on agricultural remote sensing research and applications in China[J]. Journal of remote sensing, 2016, 20(5): 748-767.
9	张王菲, 陈尔学, 李增元, 等. 雷达遥感农业应用综述[J]. 雷达学报, 2020, 9(3): 444-461.
	ZHANG W F, CHEN E X, LI Z Y, et al. Review of applications of Radar remote sensing in agriculture[J]. Journal of radars, 2020, 9(3): 444-461.
10	杨知. 基于极化SAR的水稻物候期监测与参数反演研究[D]. 北京: 中国科学院大学(中国科学院遥感与数字地球研究所), 2017.
	YANG Z. Rice phenology estimation and parameter retrieval based on polarimetric synthetic aperture radar (SAR) [D]. Beijing: University of Chinese Academy of Sciences (Institute of Remote Sensing and Digital Earth Chinese Academy of Sciences), 2017.
11	LIEW S C, CHEN P, KAM S P, et al. Rice crops monitoring in the Mekong River delta using combined ERS and RADARSAT synthetic aperture radar[C]// IGARSS ' 98. Sensing and Managing the Environment. 1998 IEEE International Geoscience and Remote Sensing. Symposium Proceedings. (Cat. No.98CH36174). Piscataway, New Jersey, USA: IEEE, 1998: 2746-2748.
12	DURDEN S L, MORRISSEY L A, LIVINGSTON G P. Microwave backscatter and attenuation dependence on leaf area index for flooded rice fields[J]. IEEE transactions on geoscience and remote sensing, 1995, 33(3): 807-810.
13	CHAKRABORTY M, PARIHAR J S, MANJUNATH K R, et al. Evaluation of ERS-1 SAR data for agricultural crop monitoring in India[J]. Geocarto international, 2002, 17(1): 69-72.
14	ASCHBACHER J, PONGSRIHADULCHAI A, KARNCHANASUTHAM S, et al. Assessment of ERS-1 SAR data for rice crop mapping and monitoring[C]// 1995 International Geoscience and Remote Sensing Symposium, IGARSS ' 95. Quantitative Remote Sensing for Science and Applications. Piscataway, New Jersey, USA: IEEE, 1995: 2183-2185.
15	KUROSU T, FUJITA M, CHIBA K. Monitoring of rice crop growth from space using theERS-1 C-band SAR[J]. IEEE transactions on geoscience and remote sensing, 1995, 33(4): 1092-1096.
16	LE TOAN T, RIBBES F, WANG L F, et al. Rice crop mapping and monitoring using ERS-1 data based on experiment and modeling results[J]. IEEE transactions on geoscience and remote sensing, 1997, 35(1): 41-56.
17	RIBBES F. Rice field mapping and monitoring withRADARSAT data[J]. International journal of remote sensing, 1999, 20(4): 745-765.
18	SHAO Y, FAN X T, LIU H, et al. Rice monitoring and production estimation using multitemporal RADARSAT[J]. Remote sensing of environment, 2001, 76(3): 310-325.
19	孙芳, 罗贤云, 尹志盈, 等. 农作物后向散射特性的测量[J]. 遥感学报, 1999, 3(2): 128-133.
	SUN F, LUO X Y, YIN Z Y, et al. Measurement of backscattering properties on crops[J]. Journal of remote sensing, 1999, 3(2): 128-133.
20	INOUE Y, KUROSU T, MAENO H, et al. Season-long daily measurements of multifrequency (Ka, Ku, X, C, and L) and full-polarization backscatter signatures over paddy rice field and their relationship with biological variables[J]. Remote sensing of environment, 2002, 81(2/3): 194-204.
21	KIM S, KIM B, KONG Y, et al. Radar backscattering measurements of rice crop using X-band scatterometer[J]. IEEE transactions on geoscience and remote sensing, 2000, 38(3): 1467-1471.
22	东朝霞, 王迪, 周清波, 等. 基于SAR遥感的北方旱地秋收作物识别研究[J]. 中国农业资源与区划, 2016, 37(8): 27-36.
	DONG Z X, WANG D, ZHOU Q B, et al. Dryland crop identification based on synthetic aperture radar in the North China plain[J]. Chinese journal of agricultural resources and regional planning, 2016, 37(8): 27-36.
23	吴永辉, 计科峰, 郁文贤. 利用SVM的全极化、双极化与单极化SAR图像分类性能的比较[J]. 遥感学报, 2008, 12(1): 46-53.
	WU Y H, JI K F, YU W X. Comparison of classification performance of full-, dual- and single-polarization SAR images using SVM[J]. Journal of remote sensing, 2008, 12(1): 46-53.
24	王迪, 周清波, 陈仲新, 等. 基于合成孔径雷达的农作物识别研究进展[J]. 农业工程学报, 2014, 30(16): 203-212.
	WANG D, ZHOU Q B, CHEN Z X, et al. Research advances on crop identification using synthetic aperture radar[J]. Transactions of the Chinese society of agricultural engineering, 2014, 30(16): 203-212.
25	MCNAIRN H, HOCHHEIM K, RABE N. Applying polarimetric radar imagery for mapping the productivity of wheat crops[J]. Canadianjournal of remote sensing, 2004, 30(3): 517-524.
26	陶亮亮, 李京, 蒋金豹, 等. 利用RADARSAT-2雷达数据与改进的水云模型反演冬小麦叶面积指数[J]. 麦类作物学报, 2016, 36(2): 236-242.
	TAO L L, LI J, JIANG J B, et al. Leaf area index inversion of winter wheat using RADARSAT-2 data and modified water-cloud model[J]. Journal of triticeae crops, 2016, 36(2): 236-242.
27	SATALINO G, MATTIA F, LE TOAN T, et al. Wheat crop mapping by usingASAR AP data[J]. IEEE transactions on geoscience and remote sensing, 2009, 47(2): 527-530.
28	OUAADI N, JARLAN L, EZZAHAR J, et al. Monitoring of wheat crops using the backscattering coefficient and the interferometric coherence derived from Sentinel-1 in semi-arid areas[J]. Remote sensing of environment, 2020, 251: ID 112050.
29	MERONI M, MARINHO E, SGHAIER N, et al. Remote sensing based yield estimation in a stochastic framework: Case study of durum wheat in Tunisia[J]. Remote sensing, 2013, 5(2): 539-557.
30	何磊. 小麦微波散射机理与生物量参数反演研究[D]. 成都: 电子科技大学, 2017.
	HE L. Research on microvave scattering mechanism and inversion of biomass of wheat [D]. Chengdu: University of Electronic Science and Technology of China, 2017.
31	MATTIA F, LE TOAN T, PICARD G, et al. Multitemporal c-band radar measurements on wheat fields[J]. IEEE transactions on geoscience and remote sensing, 2003, 41(7): 1551-1560.
32	TACONET O, VIDAL-MADJAR D, EMBLANCH C, et al. Taking into account vegetation effects to estimate soil moisture from C-band radar measurements[J]. Remote sensing of environment, 1996, 56(1): 52-56.
33	TACONET O, BENALLEGUE M, VIDAL-MADJAR D, et al. Estimation of soil and crop parameters for wheat from airborne radar backscattering data in C and X bands[J]. Remote sensing of environment, 1994, 50(3): 287-294.
34	HE F C, GU L J, ZHENG X M, et al. Semiempirical calibration of the WCM for estimating maize biomass in northeast China[J]. IEEE geoscience and remote sensing letters, 2021, 18(4): 582-586.
35	HOSSEINI M, MCNAIRN H, MERZOUKI A, et al. Estimation of leaf area index (LAI) in corn and soybeans using multi-polarization C- and L-band radar data[J]. Remote sensing of environment, 2015, 170: 77-89.
36	MANDAL D, HOSSEINI M, MCNAIRN H, et al. An investigation of inversion methodologies to retrieve the leaf area index of corn from C-band SAR data[J]. International journal of applied earth observation and geoinformation, 2019, 82: ID 101893.
37	孙盛, 刘立露, 胡忠文, 等. 基于Sentinel-1A双极化时序数据的甘蔗株高反演方法[J]. 农业机械学报, 2022, 53(2): 186-194.
	SUN S, LIU L L, HU Z W, et al. Inversion method of sugarcane plant height based on Sentinel-1A dual-polarization time series data[J]. Transactions of the Chinese society for agricultural machinery, 2022, 53(2): 186-194.
38	YANG H, YANG G J, GAULTON R, et al. In-season biomass estimation of oilseed rape (Brassica napus L.) using fully polarimetric SAR imagery[J]. Precision agriculture, 2019, 20(3): 630-648.
39	SOUYRIS J, STACY N, AINSWORTH T, et al. Sar compact polarimetry (cp) for earth observation and planetology: Concept and challenges a study case at p band[C]// International Workshop on Science and Applications of SAR Polarimetry and Polarimetric Interferometry, Noordwijk, Netherlands: European Space Agency, 2007.
40	RANEY R K, CAHILL J T S, PATTERSON G W, et al. The m-chi decomposition of hybrid dual-polarimetric radar data with application to lunar craters[J]. Journal of geophysical research: Planets, 2012, 117(E12): 5093-5096.
41	CARTER L M, CAMPBELL D B, CAMPBELL B A. Impact crater related surficial deposits on Venus: Multipolarization radar observations with Arecibo[J]. Journal of geophysical research: Planets, 2004, 109(E6): DOI:1029/2003JE002227.
42	张红, 谢镭, 王超, 等. 简缩极化SAR数据信息提取与应用[J]. 中国图象图形学报, 2013, 18(9): 1065-1073.
	ZHANG H, XIE L, WANG C, et al. Information extraction and application of compact polarimetric SAR data[J]. Journal of image and graphics, 2013, 18(9): 1065-1073.
43	杨浩. 基于时间序列全极化与简缩极化SAR的作物定量监测研究[D]. 北京: 中国林业科学研究院, 2015.
	YANG H. Study on quantitative crop monitoring by time series of fully polarimetric and compact polarimetric SAR imagery[D]. Beijing: Chinese Academy of Forestry, 2015.
44	ZHANG W F, CHEN E X, LI Z Y, et al. Rape (Brassica napus L.) growth monitoring and mapping based on radarsat-2 time-series data[J]. Remote sensing, 2018, 10(2): ID 206.
45	YANG Z, LI K, LIU L, et al. Rice growth monitoring using simulated compact polarimetricC band SAR[J]. Radio science, 2014, 49(12): 1300-1315.
46	曾亮. 多波段多极化SAR图像融合解译研究[D]. 杭州: 杭州电子科技大学, 2011.
	ZENG L. A study on multi-bands and multi-polarimetric SAR image fusion interpretation[D]. Hangzhou: Hangzhou Dianzi University, 2011.
47	MICHELSON D B, LILJEBERG B M, PILESJÖ P. Comparison of algorithms for classifying Swedish landcover using Landsat TM and ERS-1 SAR data[J]. Remote sensing of environment, 2000, 71(1): 1-15.
48	DONG J W, XIAO X M, CHEN B Q, et al. Mapping deciduous rubber plantations through integration of PALSAR and multi-temporal Landsat imagery[J]. Remote sensing of environment, 2013, 134: 392-402.
49	王乐, 樊彦国, 樊博文, 等. 基于高分卫星的冬小麦长势监测及驱动因素分析[J]. 灌溉排水学报, 2023, 42(5): 24-32, 51.
	WANG L, FAN Y G, FAN B W, et al. Monitoring winter wheat growth and analyzing its determinants using high-resolution satellite imagery[J]. Journal of irrigation and drainage, 2023, 42(5): 24-32, 51.
50	PARK J G, TATEISHI R, MATSUOKA M. A proposal of the temporal window operation (TWO) method to remove high-frequency noises in AVHRR NDVI time series data[J]. Journal of the Japan society of photogrammetry and remote sensing, 1999, 38(5): 36-47.
51	HALDAR D, TRIPATHY R, DAVE V, et al. Monitoring cotton crop condition through synergy of optical and radar remote sensing[J]. Geocarto international, 2022, 37(2): 377-395.
52	ALEBELE Y, ZHANG X E, WANG W H, et al. Estimation of canopy biomass components in paddy rice from combined optical and SAR data using multi-target Gaussian regressor stacking[J]. Remote sensing, 2020, 12(16): ID 2564.
53	WU B F, ZHANG M, ZENG H W, et al. Challenges and opportunities in remote sensing-based crop monitoring: A review[J]. Nationalscience review, 2023, 10(4): ID nwac290.
54	任建强, 刘杏认, 陈仲新, 等. 基于作物生物量估计的区域冬小麦单产预测[J]. 应用生态学报, 2009, 20(4): 872-878.
	REN J Q, LIU X R, CHEN Z X, et al. Prediction of winter wheat yield based on crop biomass estimation at regional scale[J]. Chinese journal of applied ecology, 2009, 20(4): 872-878.
55	路贵和, 安海润. 作物抗旱性鉴定方法与指标研究进展[J]. 山西农业科学, 1999, 27(4): 39-43.
	LU G H, AN H R. Progress in the research of crop drought-resistance appraise methods and indexes[J]. Journal of Shanxi agricultural sciences, 1999, 27(4): 39-43.
56	赵娟, 黄文江, 张耀鸿, 等. 冬小麦不同生育时期叶面积指数反演方法[J]. 光谱学与光谱分析, 2013, 33(9): 2546-2552.
	ZHAO J, HUANG W J, ZHANG Y H, et al. Inversion of leaf area index during different growth stages in winter wheat[J]. Spectroscopy and spectral analysis, 2013, 33(9): 2546-2552.
57	刘姣娣, 曹卫彬, 马蓉. 棉花叶面积指数的遥感估算模型研究[J]. 中国农业科学, 2008, 41(12): 4301-4306.
	LIU J D, CAO W B, MA R. Study on remote sensing estimation models about LAI of cotton[J]. Scientia agricultura sinica, 2008, 41(12): 4301-4306.
58	刘畅, 杨贵军, 李振海, 等. 融合无人机光谱信息与纹理信息的冬小麦生物量估测[J]. 中国农业科学, 2018, 51(16): 3060-3073.
	LIU C, YANG G J, LI Z H, et al. Biomass estimation in winter wheat by UAV spectral information and texture information fusion[J]. Scientia agricultura sinica, 2018, 51(16): 3060-3073.
59	兰仕浩, 李映雪, 吴芳, 等. 基于卫星光谱尺度反射率的冬小麦生物量估算[J]. 农业工程学报, 2022, 38(24): 118-128.
	LAN S H, LI Y X, WU F, et al. Winter wheat biomass estimation based on satellite spectral-scale reflectance[J]. Transactions of the Chinese society of agricultural engineering, 2022, 38(24): 118-128.
60	贺佳, 刘冰锋, 李军. 不同生育时期冬小麦叶面积指数高光谱遥感监测模型[J]. 农业工程学报, 2014, 30(24): 141-150.
	HE J, LIU B F, LI J. Monitoring model of leaf area index of winter wheat based on hyperspectral reflectance at different growth stages[J]. Transactions of the Chinese society of agricultural engineering, 2014, 30(24): 141-150.
61	WATANABE K, GUO W, ARAI K, et al. High-throughput phenotyping of sorghum plant height using an unmanned aerial vehicle and its application to genomic prediction modeling[J]. Frontiers in plant science, 2017, 8: ID 421.
62	JAMES N T. The use of bose-einstein statistics in analysing the distribution of intracellular organelles: The development of a bose-einstein probe[J]. Experientia, 1989, 45(11/12): 1078-1081.
63	龚有锐. 小麦的倒伏和防止措施[J]. 湖北农业科学, 1982, 21(9): 4-7.
	GONG Y R. Lodging of wheat and its preventive measures[J]. Hubei agricultural sciences, 1982, 21(9): 4-7.
64	CHEN J M, PAVLIC G, BROWN L, et al. Derivation and validation of Canada-wide coarse-resolution leaf area index maps using high-resolution satellite imagery and ground measurements[J]. Remote sensing of environment, 2002, 80(1): 165-184.
65	梁亮, 杨敏华, 张连蓬, 等. 基于SVR算法的小麦冠层叶绿素含量高光谱反演[J]. 农业工程学报, 2012, 28(20): 162-171, 294.
	LIANG L, YANG M H, ZHANG L P, et al. Chlorophyll content inversion with hyperspectral technology for wheat canopy based on support vector regression algorithm[J]. Transactions of the Chinese society of agricultural engineering, 2012, 28(20): 162-171, 294.
66	李云梅, 倪绍祥, 王秀珍. 线性回归模型估算水稻叶片叶绿素含量的适宜性分析[J]. 遥感学报, 2003, 7(5): 364-371.
	LI Y M, NI S X, WANG X Z. The robustness of linear regression model in rice leaf chlorophyll concentration prediction[J]. Journal of remote sensing, 2003, 7(5): 364-371.
67	PENG D L, HUANG J F, LI C J, et al. Modelling paddy rice yield using MODIS data[J]. Agricultural and forest meteorology, 2014, 184: 107-116.
68	ATZBERGER C. Advances in remote sensing of agriculture: Context description, existing operational monitoring systems and major information needs[J]. Remote sensing, 2013, 5(2): 949-981.
69	FELDMAN A F, SHORT GIANOTTI D J, TRIGO I F, et al. Land-atmosphere drivers of landscape-scale plant water content loss[J]. Geophysical research letters, 2020, 47(22): ID e2020GL090331.
70	鞠乐, 齐军仓, 陈培育, 等. 干旱胁迫对大麦种子萌发、幼苗生长及生理特性的影响[J]. 新疆农业科学, 2023, 60(8): 1879-1886.
	JU L, QI J C, CHEN P Y, et al. Effects of drought stress on seed germination, seedling growth and physiological characteristics of barley[J]. Xinjiang agricultural sciences, 2023, 60(8): 1879-1886.
71	安文韬. 基于极化SAR的目标极化分解与散射特征提取研究[D]. 北京: 清华大学, 2010.
	AN W T. The polarimetric decomposition and scattering characteristic extraction of polarimetric SAR[D]. Beijing: Tsinghua University, 2010.
72	KIM Y, JACKSON T, BINDLISH R, et al. Retrieval of wheat growth parameters with radar vegetation indices[J]. IEEE geoscience and remote sensing letters, 2014, 11(4): 808-812.
73	尼格拉·吐尔逊, 依力亚斯江·努尔麦麦提, 王远弘, 等. 基于H/A/α分解全极化合成孔径雷达数据的干旱区土壤盐渍化分类[J]. 江苏农业科学, 2019, 47(22): 273-279.
	NIGELA T, YILIYASIJIANG N, WANG Y H, et al. Classification of soil salinization in arid areas based on H/A/α polarimetric decomposition method of POLSAR data[J]. Jiangsu agricultural sciences, 2019, 47(22): 273-279.
74	FERRO-FAMIL L, POTTIER E, LEE J S. Unsupervised classification of multifrequency and fully polarimetricSAR images based on the H/A/Alpha-wishart classifier[J]. IEEE transactions on geoscience and remote sensing, 2001, 39(11): 2332-2342.
75	MACRÌ PELLIZZERI T. Classification of polarimetric SAR images of suburban areas using joint annealed segmentation and "H/A/α" polarimetric decomposition[J]. ISPRS journal of photogrammetry and remote sensing, 2003, 58(1/2): 55-70.
76	张微, 林健, 陈玲, 等. 基于极化分解的极化SAR数据地质信息提取方法研究[J]. 遥感信息, 2014, 29(1): 10-14.
	ZHANG W, LIN J, CHEN L, et al. Geological information extraction using polarimetric SAR based on polarization decomposition[J]. Remote sensing information, 2014, 29(1): 10-14.
77	CLOUDE S R, POTTIER E. A review of target decomposition theorems in radar polarimetry[J]. IEEE transactions on geoscience and remote sensing, 1996, 34(2): 498-518.
78	赵丽仙, 张王菲, 李云, 等. 基于高分三号卫星数据与H/A/ α ¯ 分解特征参数的农作物分类研究[J]. 浙江农业学报, 2022, 34(11): 2491-2503.
	ZHAO L X, ZHANG W F, LI Y, et al. Crops classification based on GF-3 satellite data and H/A/ α ¯ decomposition characteristic parameters[J]. Acta agriculturae Zhejiangensis, 2022, 34(11): 2491-2503.
79	张继超, 郭伟, 周沛希. 雷达植被指数与香农熵在GF-3影像分类中的应用[J]. 测绘科学, 2020, 45(10): 48-54.
	ZHANG J C, GUO W, ZHOU P X. Application of radar vegetation index and Shannon entropy in GF-3 image classification[J]. Science of surveying and mapping, 2020, 45(10): 48-54.
80	WISEMAN G, MCNAIRN H, HOMAYOUNI S, et al. RADARSAT-2 polarimetric SAR response to crop biomass for agricultural production monitoring[J]. IEEE journal of selected topics in applied earth observations and remote sensing, 2014, 7(11): 4461-4471.
81	ULABY F. Radar measurement of soil moisture content[J]. IEEE transactions on antennas and propagation, 1974, 22(2): 257-265.
82	ULABY F T, BATLIVALA P P, DOBSON M C. Microwave backscatter dependence on surface roughness, soil moisture, and soil texture: Part I-bare soil[J]. IEEE transactions on geoscience electronics, 1978, 16(4): 286-295.
83	ULABY F. Radar response to vegetation[J]. IEEE transactions on antennas and propagation, 1975, 23(1): 36-45.
84	KIM Y, JACKSON T, BINDLISH R, et al. Radar vegetation index for estimating the vegetation water content of rice and soybean[J]. IEEE geoscience and remote sensing letters, 2012, 9(4): 564-568.
85	NASIRZADEHDIZAJI R, BALIK SANLI F, ABDIKAN S, et al. Sensitivity analysis of multi-temporal sentinel-1 SAR parameters to crop height and canopy coverage[J]. Applied sciences, 2019, 9(4): ID 655.
86	MANDAL D, KUMAR V, RATHA D, et al. Dual polarimetric radar vegetation index for crop growth monitoring using Sentinel-1 SAR data[J]. Remote sensing of environment, 2020, 247: ID 111954.
87	RATHA D, MANDAL D, KUMAR V, et al. A generalized volume scattering model-based vegetation index from polarimetric SAR data[J]. IEEE geoscience and remote sensing letters, 2019, 16(11): 1791-1795.
88	MANDAL D, RATHA D, BHATTACHARYA A, et al. A radar vegetation index for crop monitoring using compact polarimetric SAR data[J]. IEEE transactions on geoscience and remote sensing, 2020, 58(9): 6321-6335.
89	董彦芳, 孙国清, 庞勇. 基于ENVISAT ASAR数据的水稻监测[J]. 中国科学(D辑: 地球科学), 2005, 35(7): 682-689.
	DONG Y F, SUN G Q, PANG Y. Rice monitoring based on ENVISAT ASAR data[J]. Science in China, SerD, 2005, 35(7): 682-689.
90	CHEN J S, LIN H, PEI Z Y. Application of ENVISAT ASAR data in mapping rice crop growth in southern China[J]. IEEE geoscience and remote sensing letters, 2007, 4(3): 431-435.
91	DENTE L, SATALINO G, MATTIA F, et al. Assimilation of leaf area index derived from ASAR and MERIS data into CERES-Wheat model to map wheat yield[J]. Remote sensing of environment, 2008, 112(4): 1395-1407.
92	ZHANG W F, CHEN E X, LI Z Y, et al. Using compact polarimetric parameters for rape (Brassica napus L.) LAI inversion[C]// 2017 IEEE International Geoscience and Remote Sensing Symposium (IGARSS). Piscataway, New Jersey, USA: IEEE, 2017: 5846-5849.
93	MCNAIRN H, BRISCO B. The application of C-band polarimetric SAR for agriculture: A review[J]. Canadian journal of remote sensing, 2004, 30(3): 525-542.
94	康伟, 张王菲, 张亚红, 等. 小麦生物量极化分解参数响应及反演[J]. 沈阳农业大学学报, 2019, 50(5): 585-594.
	KANG W, ZHANG W F, ZHANG Y H, et al. Inversion and polarimetric information response analysis of wheat biomass[J]. Journal of Shenyang agricultural university, 2019, 50(5): 585-594.
95	XU F, JIN Y Q. Deorientation theory of polarimetric scattering targets and application to terrain surface classification[J]. IEEE transactions on geoscience and remote sensing, 2005, 43(10): 2351-2364.
96	LIU C, SHANG J L, VACHON P W, et al. Multiyear crop monitoring using polarimetric RADARSAT-2 data[J]. IEEE transactions on geoscience and remote sensing, 2013, 51(4): 2227-2240.
97	FREEMAN A, DURDEN S L. A three-component scattering model for polarimetricSAR data[J]. IEEE transactions on geoscience and remote sensing, 1998, 36(3): 963-973.
98	CANISIUS F, FERNANDES R. ALOS PALSAR L-band polarimetric SAR data and in situ measurements for leaf area index assessment[J]. Remote sensing letters, 2012, 3(3): 221-229.
99	BLAES X, VANHALLE L, DEFOURNY P. Efficiency of crop identification based on optical and SAR image time series[J]. Remote sensing of environment, 2005, 96(3/4): 352-365.
100	张亚红, 吴娇娇, 胥喆, 等. 合成孔径雷达在农作物长势监测中的应用[J]. 安徽农业科学, 2016, 44(27): 220-222, 244.
	ZHANG Y H, WU J J, XU Z, et al. Application of synthetic aperture radar in crop growth monitoring[J]. Journal of Anhui agricultural sciences, 2016, 44(27): 220-222, 244.
101	YANG Z, LI K, SHAO Y, et al. Estimation of paddy rice variables with a modified water cloud model and improved polarimetric decomposition using multi-temporal RADARSAT-2 images[J]. Remote sensing, 2016, 8(10): ID 878.
102	CANISIUS F, SHANG J L, LIU J G, et al. Tracking crop phenological development using multi-temporal polarimetric RADARSAT-2 data[J]. Remote sensing of environment, 2018, 210: 508-518.
103	JIAO X F, MCNAIRN H, SHANG J L, et al. The sensitivity of RADARSAT-2 polarimetric SAR data to corn and soybean leaf area index[J]. Canadian journal of remote sensing, 2011, 37(1): 69-81.
104	邹斌, 张腊梅, 孙德明, 等. PolSAR图像信息提取技术及应用的发展[J]. 遥感技术与应用, 2009, 24(3): 263-273.
	ZOU B, ZHANG L M, SUN D M, et al. Development and application of information extraction using polarimetric SAR data[J]. Remote sensing technology and application, 2009, 24(3): 263-273.
105	张腊梅, 段宝龙, 邹斌. 极化SAR图像目标分解方法的研究进展[J]. 电子与信息学报, 2016, 38(12): 3289-3297.
	ZHANG L M, DUAN B L, ZOU B. Research development on target decomposition method of polarimetric SAR image[J]. Journal of electronics & information technology, 2016, 38(12): 3289-3297.
106	DEY S, BHATTACHARYA A, RATHA D, et al. Target characterization and scattering power decomposition for full and compact polarimetric SAR data[J]. IEEE transactions on geoscience and remote sensing, 2021, 59(5): 3981-3998.
107	LEE J S, POTTIER E. Polarimetric radar imaging: From basics to applications[M]. Boca Raton: Crc Press-Taylor & Francis Group, 2009.
108	CLOUDE S. Polarisation: Applications in remote sensing[M]. Oxford: Oxford University Press, 2009.
109	SOUYRIS J C, IMBO P, FJORTOFT R, et al. Compact polarimetry based on symmetry properties of geophysical media: The/spl Pi// 4 mode[J]. IEEE transactions on geoscience and remote sensing, 2005, 43(3): 634-646.
110	ZHANG H, XIE L, WANG C, et al. Investigation of the capability of h-alpha decomposition of compact polarimetric SAR[J]. IEEE geoscience and remote sensing letters, 2014, 11(4): 868-872.
111	RANEY R. Hybrid-polarity SAR architecture[C]// 2007 IEEE International Symposium on Geoscience and Remote Sensing. Piscataway, New Jersey, USA: IEEE, 2007: 3397-3404.
112	ULABY F T, SARABANDI K, MCDONALD K, et al. Michigan microwave canopy scattering model[J]. Internationaljournal of remote sensing, 1990, 11(7): 1223-1253.
113	STILES J M, SARABANDI K. Electromagnetic scattering from grassland. Part I. A fully phase-coherent scattering model[J]. IEEE transactions on geoscience and remote sensing, 2000, 38(1): 339-348.
114	LIANG P, PIERCE L E, MOGHADDAM M. Radiative transfer model for microwave bistatic scattering from forest canopies[J]. IEEE transactions on geoscience and remote sensing, 2005, 43(11): 2470-2483.
115	TOURE A, THOMSON K P B, EDWARDS G, et al. Adaptation of theMIMICS backscattering model to the agricultural context-wheat and canola at L and C bands[J]. IEEE transactions on geoscience and remote sensing, 1994, 32(1): 47-61.
116	李昕. 基于全极化SAR图像的植被信息提取技术研究[D]. 成都: 电子科技大学, 2015.
	LI X. Technology research of vegetation information extraction based on fully polarimetric SAR image[D]. Chengdu: University of Electronic Science and Technology of China, 2015
117	吴学睿. GNSS-R陆面遥感散射特性研究[D]. 大连: 大连海事大学, 2012.
	WU X R. GNSS-R land surface remote sensing scattering properties study[D]. Dalian: Dalian Maritime University, 2012.
118	JIA M Q, TONG L, ZHANG Y Z, et al. Rice biomass estimation using radar backscattering data at S-band[J]. IEEE journal of selected topics in applied earth observations and remote sensing, 2014, 7(2): 469-479.
119	LANG R, SALEH H. Microwave inversion of leaf area and inclination angle distributions from backscattered data[J]. IEEE transactions on geoscience and remote sensing, 1985, GE-23(5): 685-694.
120	KASISCHKE E S, CHRISTENSEN N L. Connecting forest ecosystem and microwave backscatter models[J]. International journal of remote sensing, 1990, 11(7): 1277-1298.
121	CHEN G Q, ZHANG J W, LIU P, et al. An empirical model for changes in the leaf area of maize[J]. Canadian journal of plant science, 2014, 94(4): 749-757.
122	杨沈斌. 基于ASAR数据的水稻制图与水稻估产研究[D]. 南京: 南京信息工程大学, 2008.
	YANG S B. Study on rice mapping and rice yield estimation based on ASAR data[D]. Nanjing: Nanjing University of Information, 2008.
123	东朝霞. 基于全极化SAR数据的旱地作物识别与生物学参数反演研究[D]. 北京: 中国农业科学院, 2016.
	DONG Z X. Dryland crop identification and biological parameters estimation based on full-polarization SAR data[D]. Beijing: Chinese Academy of Agricultural Sciences, 2016.
124	张晓倩, 刘湘南, 谭正. 基于全极化RADARSAT-2数据的水稻生物量估算模型[J]. 农业现代化研究, 2012, 33(2): 249-252.
	ZHANG X Q, LIU X N, TAN Z. Rice biomass estimation based on full-polarization radarsat-2 data[J]. Research of agricultural modernization, 2012, 33(2): 249-252.
125	SINGH D. Scatter meter performance with polarization discrimination ratio approach to retrieve crop soybean parameter at X-band[J]. International journal of remote sensing, 2006, 27(19): 4101-4115.
126	NDIKUMANA E, TONG MINH DHO, DANG NGUYEN H, et al. Estimation of rice height and biomass using multitemporal SAR Sentinel-1 for Camargue, Southern France[J]. Remote sensing, 2018, 10(9): ID 1394.
127	BAGHDADI N, HOLAH N, ZRIBI M. Soil moisture estimation using multi-incidence and multi-polarizationASAR data[J]. International journal of remote sensing, 2006, 27(10): 1907-1920.
128	许涛, 廖静娟, 沈国状, 等. 植被微波散射模型研究综述[J]. 遥感信息, 2015, 30(5): 3-13.
	XU T, LIAO J J, SHEN G Z, et al. Progresses on microwave scattering model of vegetation[J]. Remote sensing information, 2015, 30(5): 3-13.
129	ATTEMA E P W, ULABY F T. Vegetation modeled as a water cloud[J]. Radioscience, 1978, 13(2): 357-364.
130	CHAMPION I, PREVOT L, GUYOT G. Generalized semi-empirical modelling of wheat radar response[J]. Internationaljournal of remote sensing, 2000, 21(9): 1945-1951.
131	BÉRIAUX E, WALDNER F, COLLIENNE F, et al. Maize leaf area index retrieval from synthetic quad pol SAR time series using the water cloud model[J]. Remote sensing, 2015, 7(12): 16204-16225.
132	张晓倩, 郭琳, 马尚杰, 等. 利用时序合成孔径雷达数据监测水稻叶面积指数[J]. 农业工程学报, 2014, 30(13): 185-193.
	ZHANG X Q, GUO L, MA S J, et al. Monitoring rice leaf area index using time-series SAR data[J]. Transactions of the Chinese society of agricultural engineering, 2014, 30(13): 185-193.
133	DE ROO R D, DU Y, ULABY F T, et al. A semi-empirical backscattering model at L-band and C-band for a soybean canopy with soil moisture inversion[J]. IEEE transactions on geoscience and remote sensing, 2001, 39(4): 864-872.
134	陈怀亮, 李颖, 张红卫. 农作物长势遥感监测业务化应用与研究进展[J]. 气象与环境科学, 2015, 38(1): 95-102.
	CHEN H L, LI Y, ZHANG H W. Operational application and research review of crop growth monitoring with remote sensing[J]. Meteorological and environmental sciences, 2015, 38(1): 95-102.
135	KIM Y, HONG S, LEE K, et al. Estimating wheat growth for radar vegetation indices[C]// 2013 IEEE International Geoscience and Remote Sensing Symposium - IGARSS. Piscataway, New Jersey, USA: IEEE, 2013: 3219-3222.
136	HALDAR D, DAVE V, MISRA A, et al. Radar Vegetation Index for assessing cotton crop condition using RISAT-1 data[J]. Geocarto international, 2020, 35(4): 364-375.
137	赵艳霞, 周秀骥, 梁顺林. 遥感信息与作物生长模式的结合方法和应用——研究进展[J]. 自然灾害学报, 2005, 14(1): 103-109.
	ZHAO Y X, ZHOU X J, LIANG S L. Methods and application of coupling remote sensing data and crop growth models: Advance in research[J]. Journal of natural disasters, 2005, 14(1): 103-109.
138	DENTE L, RINALDI M, MATTIA F, et al. On the assimilation of C-band radar data into CERES-wheat model[C]// IEEE International Geoscience and Remote Sensing Symposium, 2004. IGARSS ' 04. Proceedings. 2004. Piscataway, New Jersey, USA: IEEE, 2004: 1284-1287.
139	谭正. 基于SAR数据和作物生长模型同化的水稻长势监测与估产研究[D]. 北京: 中国地质大学(北京), 2012.
	TAN Z. Study on rice growth monitoring and yield prediction based on assimilation of SAR data and crop growth model[D]. Beijing: China University of Geosciences, 2012.

分类	参数名称	定义
形态指标	株高（Plant Height）^［61］	植物的根茎部到顶部的距离，其中顶部是指植物的主干顶
	冠层覆盖度（Canopy Coverage）^［62］	植物冠层覆盖地表的面积与该区域表面积之比，通常用百分比表示
	倒伏率（Fall Rate）^［63］	分为根倒和茎折。根倒是指倒伏倾斜度大于45°者作为倒伏指标，以百分比表示；茎折是指抽雄后，果穗以下部位折断的植株占全区株树的百分比
生理生化指标	叶面积指数（Leaf Area Index）^［64］	单位土地面积上植物叶片总面积与该土地面积之比
生理生化指标	叶片叶绿素含量（Leaf Chlorophyll Content）^{［65， 66］}	叶片中所含叶绿素的量。测定叶片叶绿素含量可以反映叶片光合能力和生长状态
产量指标	生物量（Biomass）^{［67， 68］}	某一时刻单位面积内实存生活的有机物质（干重）总量，通常用kg/m²或t/ha表示。
胁迫指标	植株含水量（Plant Water Content）^［69］	植被冠层体积内的含水量，其动态可以捕捉植物的水分胁迫
胁迫指标	干旱胁迫（Drought Stress）因子^［70］	由于干旱条件下植物获取的水分有限，因此植物生长明显受到抑制的现象
