Spectral Technology in Vegetable Production Detection: Research Progress, Challenges and Suggestions

BAI Juekun1,2(), LIU Yachao2, DONG Daming1,2(), YUE Xiaolong2, DU Xiuke2

  1. 1. School of Agricultural Engineering, Jiangsu University, Zhenjiang 212013, China
    2. National Research Center of Intelligent Equipment for Agriculture, Beijing Academy of Agriculture and Forestry Sciences, Beijing 100097, China
  • Received:2025-04-22 Online:2025-08-14
  • Foundation items:National Key Research and Development Program of China(2022YFD2002101)
  • About author:

    BAI Juekun, E-mail:

  • corresponding author:
    DONG Daming, E-mail:

Abstract:

[Significance] Vegetables are indispensable to global food security and human nutrition, yet approximately 33% of the annual 1.2 billion-ton harvest is lost or wasted, largely because of undetected biotic and abiotic stresses, poor post-harvest management, and chemical safety hazards. Conventional analytical workflows—based on wet chemistry and chromatography—are destructive, labour-intensive, and difficult to scale, creating an urgent need for rapid, non-invasive sensing tools that can operate across the full production-to-consumption continuum. Optical spectroscopy, spanning near-infrared (NIR), Raman, fluorescence, laser-induced breakdown spectroscopy (LIBS), and UV–Vis modalities, offers label-free, multiplexed, and second-scale measurements directly on living plants or minimally processed products. Existing reviews have concentrated on isolated techniques or single application niches, leaving critical knowledge gaps regarding hardware robustness under open-field conditions, algorithmic generalisability across cultivars and climates, data interoperability, and cost-driven adoption barriers for smallholders. [Progress] This paper present a holistic, chain-wide appraisal of spectroscopic sensing in vegetable production. We show that: Hardware evolution has been dominated by miniaturisation and functional integration. Hand-held NIR units (e.g., Neospectra MEMS, NirVana AG410) now weigh <300 g and achieve R² > 0.95 for soluble solids and moisture in tomato, zucchini, and pepper. Palm-top Raman systems (9 × 7 × 4 cm) equipped with 1 064 nm lasers and InGaAs detectors suppress fluorescence sufficiently to quantify lycopene (RMSE = 1.14 mg/100 g) and classify ripeness stages with 100 % accuracy. Battery-powered fluorescence sensors coupled with smartphones wirelessly stream data to cloud-based convolutional neural networks (CNNs), delivering 93%–100% correct cultivar identification for spinach, onion, and tomato seeds within 5 s per sample. Methodological advances combine advanced chemometrics and deep learning. Transfer learning enables a model trained on greenhouse tomatoes to predict field-grown cherry tomatoes with only 10% recalibration samples, cutting data acquisition costs by 70 %. SERS substrates—fabricated as flexible "place-and-play" nano-mesh films—boost Raman signals by 10⁶–10⁸, pushing limits of detection for carbaryl, imidacloprid, and thiamethoxam below 1 mg kg⁻¹ on pak-choi and lettuce. Multi-modal fusion (LIBS-NIR) simultaneously quantifies macro-elements (Ca, K, Mg) and micro-elements (Fe, Mn) with relative errors <5 %. Chain-wide demonstrations span five critical stages: (i) breeding—NIR screens seed viability via starch and moisture signatures; (ii) cultivation—portable Raman "leaf-clip" sensors detect nitrate deficiency (1 045 cm⁻¹ peak) and early pathogen attack (LsoA vs. LsoB, 80% accuracy) in lettuce and tomato before visible symptoms emerge; (iii) harvest—non-invasive lycopene monitoring in tomato and carotenoid profiling in chilli guides optimal picking time and reduces post-harvest losses by 15%; (iv) storage—chlorophyll fluorescence tracks water loss and senescence in black radish and carrot over six-month cold storage, enabling dynamic shelf-life prediction; (v) market entry—LIBS inspects incoming crates for Pb and Cd in seconds, while fluorescence-SVM pipelines simultaneously verify pesticide residues, ensuring compliance with EU and Chinese MRLs. Data governance initiatives are emerging but remain fragmented. Several consortia have released open spectral libraries (e.g., VegSpec-1.0 with 50 000 annotated spectra from 30 vegetable species), yet differences in acquisition parameters, preprocessing pipelines, and metadata schemas hinder cross-study reuse. Conclusions and Prospects Spectroscopic sensing has matured from laboratory proof-of-concept to robust field prototypes capable of guiding real-time decisions across the entire vegetable value chain. Nevertheless, four priority areas must be addressed to unlock global adoption: Model generalisation—curate large-scale, multi-environment, multi-cultivar spectral repositories and embed meta-learning algorithms that continuously adapt to new genotypes and climates with minimal retraining. Hardware resilience—develop self-calibrating sensors with adaptive optics and real-time environmental compensation (temperature, humidity, ambient light) to maintain laboratory-grade SNR in dusty, humid, or high-irradiance field settings. Standardisation and interoperability—establish ISO-grade protocols for hardware interfaces, data formats, calibration transfer, and privacy-preserving data sharing, enabling seamless integration of devices, clouds, and decision-support platforms. Cost-effective commercialisation—pursue modular, open-hardware designs leveraging printed optics and economies of scale to reduce unit costs below USD 500, and introduce service-based models (leasing, pay-per-scan) tailored to smallholder economics. If these challenges are met, spectroscopy-based digital twins of vegetable production systems could become a reality, delivering safer food, reduced waste, and climate-smart agriculture within the next decade.

Key words: spectrum technology, near-infrared spectroscopy, Raman spectroscopy, fluorescence spectroscopy, vegetables, on-site detection

CLC Number:
