Welcome to Smart Agriculture
30 January 2024, Volume 6 Issue 1
Topic--Intelligent Agricultural Sensor Technology
Agricultural Sensor: Research Progress, Challenges and Perspectives | Open Access
WANG Rujing
2024, 6(1):  1-17.  doi:10.12133/j.smartag.SA202401017
Asbtract ( 264 )   HTML ( 47)   PDF (1179KB) ( 122 )
Figures and Tables | References | Related Articles | Metrics

Significance Agricultural sensor is the key technology for developing modern agriculture. Agricultural sensor is a kind of detection device that can sense and convert physical signal, which is related to the agricultural environment, plants and animals, into an electrical signal. Agricultural sensors could be applied to monitor crops and livestock in different agricultural environments, including weather, water, atmosphere and soil. It is also an important driving force to promote the iterative upgrading of agricultural technology and change agricultural production methods. Progress The different agricultural sensors are categorized, the cutting-edge research trends of agricultural sensors are analyzed, and summarizes the current research status of agricultural sensors are summarized in different application scenarios. Moreover, a deep analysis and discussion of four major categories is conducted, which include agricultural environment sensors, animal and plant life information sensors, agricultural product quality and safety sensors, and agricultural machinery sensors. The process of research, development, the universality and limitations of the application of the four types of agricultural sensors are summarized. Agricultural environment sensors are mainly used for real-time monitoring of key parameters in agricultural production environments, such as the quality of water, gas, and soil. The soil sensors provide data support for precision irrigation, rational fertilization, and soil management by monitoring indicators such as soil humidity, pH, temperature, nutrients, microorganisms, pests and diseases, heavy metals and agricultural pollution, etc. Monitoring of dissolved oxygen, pH, nitrate content, and organophosphorus pesticides in irrigation and aquaculture water through water sensors ensures the rational use of water resources and water quality safety. The gas sensor monitors the atmospheric CO2, NH3, C2H2, CH4 concentration, and other information, which provides the appropriate environmental conditions for the growth of crops in greenhouses. The animal life information sensor can obtain the animal's growth, movement, physiological and biochemical status, which include movement trajectory, food intake, heart rate, body temperature, blood pressure, blood glucose, etc. The plant life information sensors monitor the plant's health and growth, such as volatile organic compounds of the leaves, surface temperature and humidity, phytohormones, and other parameters. Especially, the flexible wearable plant sensors provide a new way to measure plant physiological characteristics accurately and monitor the water status and physiological activities of plants non-destructively and continuously. These sensors are mainly used to detect various indicators in agricultural products, such as temperature and humidity, freshness, nutrients, and potentially hazardous substances (e.g., bacteria, pesticide residues, heavy metals, etc. Agricultural machinery sensors can achieve real-time monitoring and controlling of agricultural machinery to achieve real-time cultivation, planting, management, and harvesting, automated operation of agricultural machinery, and accurate application of pesticide, fertilizer. [Conclusions and Prospects In the challenges and prospects of agricultural sensors, the core bottlenecks of large-scale application of agricultural sensors at the present stage are analyzed in detail. These include low-cost, specialization, high stability, and adaptive intelligence of agricultural sensors. Furthermore, the concept of "ubiquitous sensing in agriculture" is proposed, which provides ideas and references for the research and development of agricultural sensor technology.

Contactless Conductivity Microfluidic Chip for Rapid Determination of Soil Nitrogen and Potassium Content | Open Access
HONG Yan, WANG Le, WANG Rujing, SU Jingming, LI Hao, ZHANG Jiabao, GUO Hongyan, CHEN Xiangyu
2024, 6(1):  18-27.  doi:10.12133/j.smartag.SA202309022
Asbtract ( 69 )   HTML ( 13)   PDF (1344KB) ( 55 )
Figures and Tables | References | Related Articles | Metrics

Objective The content of nitrogen (N) and potassium (K) in the soil directly affects crop yield, making it a crucial indicator in agricultural production processes. Insufficient levels of the two nutrients can impede crop growth and reduce yield, while excessive levels can result in environmental pollution. Rapidly quantifying the N and K content in soil is of great importance for agricultural production and environmental protection. Methods A rapid and quantitative method was proposed for detecting N and K nutrient ions in soil based on polydimethylsiloxane (PDMS) microfluidic chip electrophoresis and capacitively coupled contactless conductivity detection (C4D). Microfluidic chip electrophoresis enables rapid separation of multiple ions in soil. The electrophoresis microfluidic chips have a cross-shaped channel layout and were fabricated using soft lithography technology. The sample was introduced into the microfluidic chip by applying the appropriate injection voltage at both ends of the injection channel. This simple and efficient procedure ensured an accurate sample introduction. Subsequently, an electrophoretic voltage was applied at both ends of the separation channel, creating a capillary zone electrophoresis that enables the rapid separation of different ions. This process offered high separation efficiency, required a short processing time, and had a small sample volume requirement. This enabled the rapid processing and analysis of many samples. C4D enabled precise measurement of changes in conductivity. The sensing electrodes were separated from the microfluidic chips and printed onto a printed circuit board (PCB) using an immersion gold process. The ions separated under the action of an electric field and sequentially reach the sensing electrodes. The detection circuit, connected to the sensing electrodes, received and regulated the conductivity signal to reflect the variance in conductivity between the sample and the buffer solution. The sensing electrodes were isolated from the sample solution to prevent interference from the high-voltage electric field used for electrophoresis. Results and Discussions The voltage used for electrophoresis, as well as the operating frequency and excitation voltage of the excitation signal in the detection system, had a significant effect on separation and detection performance. Based on the response characteristics of the system output, the optimal operating frequency of 1 000 kHz, excitation voltage of 50 V, and electrophoresis voltage of 1.5 kV were determined. A peak overshoot was observed in the electrophoresis spectrum, which was associated with the operating frequency of the system. The total noise level of the system was approximately 0.091 mV. The detection limit (S/N = 3) for soil nutrient ions was determined by analyzing a series of standard sample solutions with varying concentrations. The detection limited for potassium (K+), ammonium (NH4+), and nitrate (NO3) standard solutions were 0.5, 0.1 and 0.4 mg/L, respectively. For the quantitative determination of soil nutrient ion concentration, the linear relationship between peak area and corresponding concentration was investigated under optimal experimental conditions. K+, NH4+, and NO3 exhibit a strong linear relationship in the range of 0.5~40 mg/L, with linear correlation coefficients (R2) of 0.994, 0.997, and 0.990, respectively, indicating that this method could accurately quantify N and K ions in soil. At the same time, to evaluate the repeatability of the system, peak height, peak area, and peak time were used as evaluation indicators in repeatability experiments. The relative standard deviation (RSD) was less than 4.4%, indicating that the method shows good repeatability. In addition, to assess the ability of the C4D microfluidic system to detect actual soil samples, four collected soil samples were tested using MES/His and PVP/PTAE as running buffers. K+, NH4+,Na+, Chloride (Cl), NO3, and sulfate (SO43‒) were separated sequentially within 1 min. The detection efficiency was significantly improved. To evaluate the accuracy of this method, spiked recovery experiments were performed on four soil samples. The recovery rates ranged from 81.74% to 127.76%, indicating the good accuracy of the method. Conclusions This study provides a simple and effective method for the rapid detection of N and K nutrient ions in soil. The method is highly accurate and reliable, and it can quickly and efficiently detect the contents of N and K nutrient ions in soil. This contactless measurement method reduced costs and improved economic efficiency while extending the service life of the sensing electrodes and reducing the frequency of maintenance and replacement. It provided strong support for long-term, continuous conductivity monitoring.

Capacitive Soil Moisture Sensor Based on MoS2 | Open Access
LI Lu, GE Yuqing, ZHAO Jianlong
2024, 6(1):  28-35.  doi:10.12133/j.smartag.SA202309020
Asbtract ( 39 )   HTML ( 6)   PDF (1373KB) ( 40 )
Figures and Tables | References | Related Articles | Metrics

Objective The soil moisture content is a crucial factor that directly affected the growth and yield of crops. By using a soil measurement instrument to measure the soil's moisture content, lots of powerful data support for the development of agriculture can be provided. Furthermore, these data have guiding significance for the implementation of scientific irrigation and water-saving irrigation in farmland. In order to develop a reliable and efficient soil moisture sensor, a new capacitive soil moisture sensor based on microfabrication technology was proposed in this study. Capacitive moisture sensors have the advantages of low power consumption, good performance, long-term stability, and easy industrialization. Method The forked electrode array consists of multiple capacitors connected in parallel on the same plane. The ideal design parameters of 10 μm spacing and 75 pairs of forked electrodes were obtained by calculating the design of forked finger logarithms, forked finger spacing, forked finger width, forked finger length, and electrode thickness, and studying the influence of electrode parameters on capacitance sensitivity using COMSOL Multiphysics software. The size obtained an initial capacitance on the order of picofarads, and was not easily breakdown or failed. The sensor was constructed using microelectromechanical systems (MEMS) technology, where a 30 nm titanium adhesion layer was sputtered onto a glass substrate, followed by sputtering a 100 nm gold electrode to form a symmetrical structure of forked electrodes. Due to the strong adsorption capacity of water molecules of the MoS2 (molybdenum disulfide) layer, it exhibited high sensitivity to soil moisture and demonstrated excellent soil moisture sensing performance. The molybdenum disulfide was coated onto the completed electrodes as the humidity-sensitive material to create a humidity sensing layer. When the humidity changed, the dielectric constant of the electrode varied due to the moisture-absorbing characteristics of molybdenum disulfide, and the capacitance value of the device changed accordingly, thus enabling the measurement of soil moisture. Subsequently, the electrode was encapsulated with a polytetrafluoroethylene (PTFE) polymer film. The electrode encapsulated with the microporous film could be directly placed in the soil, which avoided direct contact between the soil/sand particles and the molybdenum disulfide on the device and allowed the humidity sensing unit to only capture the moisture in the soil for measuring humidity. This ensured the device's sensitivity to water moisture and improved its long-term stability. The method greatly reduced the size of the sensor, making it an ideal choice for on-site dynamic monitoring of soil moisture. Results and Discussions The surface morphology of molybdenum disulfide was characterized and analyzed using a Scanning Electron Microscope (SEM). It was observed that molybdenum disulfide nanomaterial exhibited a sheet-like two-dimensional structure, with smooth surfaces on the nanosheets. Some nanosheets displayed sharp edges or irregular shapes along the edges, and they were irregularly arranged with numerous gaps in between. The capacitive soil moisture sensor, which utilized molybdenum disulfide as the humidity-sensitive layer, exhibited excellent performance under varying levels of environmental humidity and soil moisture. At room temperature, a humidity generator was constructed using saturated salt solutions. Saturated solutions of lithium chloride, potassium acetate, magnesium chloride, copper chloride, sodium chloride, potassium chloride, and potassium sulfate were used to generate relative humidity levels of 11%, 23%, 33%, 66%, 75%, 84%, and 96%, respectively. The capacitance values of the sensor were measured at different humidity levels using an LCR meter (Agilent E4980A). The capacitance output of the sensor at a frequency of 200 Hz ranged from 12.13 pF to 187.42 nF as the relative humidity varied between 11% to 96%. The sensor exhibited high sensitivity and a wide humidity sensing range. Additionally, the frequency of the input voltage signal had a significant impact on the capacitance output of the sensor. As the testing frequency increased, the response of the sensor's system decreased. The humidity sensing performance of the sensor was tested in soil samples with moisture content of 8.66%, 13.91%, 22.02%, 31.11%, and 42.75%, respectively. As the moisture content in the soil increased from 8.66% to 42.75%, the capacitance output of the sensor at a frequency of 200 Hz increased from 119.51 nF to 377.98 nF, demonstrating a relatively high sensitivity. Similarly, as the frequency of the input voltage increased, the capacitance output of the sensor decreased. Additionally, the electrode exhibited good repeatability and the sensitivity of the sensor increased significantly as the testing frequency decreased. Conclusions The capacitive soil moisture sensor holds promise for effective and accurate monitoring of soil moisture levels, with its excellent performance, sensitivity, repeatability, and responsiveness to changes in humidity and soil moisture. The ultimate goal of this study is to achieve long-term monitoring of capacitance changes in capacitive soil moisture sensors, enabling monitoring of long-term changes in soil moisture. This will enable farmers to optimize irrigation systems, improve crop yields, and reduce water usage. In conclusion, the development of this innovative soil moisture sensor has the potential to promote agricultural modernization by providing accurate and reliable monitoring of soil moisture levels.

Automatic Identification Method for Spectral Peaks of Soil Nutrient Ions Using Contactless Conductivity Detection | Open Access
TANG Chaoli, LI Hao, WANG Rujing, WANG Le, HUANG Qing, WANG Dapeng, ZHANG Jiabao, CHEN Xiangyu
2024, 6(1):  36-45.  doi:10.12133/j.smartag.SA202309028
Asbtract ( 29 )   HTML ( 3)   PDF (2822KB) ( 36 )
Figures and Tables | References | Related Articles | Metrics

Objective Capacitive coupled contactless conductivity detection (C4D) plays an important role in agricultural soil nutrient ion detection. Effective identification of characteristic ion peaks in C4D signals is conducive to subsequent qualitative and quantitative analysis of characteristic ion peaks, which provides a basis for improving agricultural soil nutrient management. However, the detection of characteristic peaks in C4D signals still has shortcomings, such as the inability of automatic and accurate identification, complicated manual operation, and low efficiency. Methods In this study, an automatic spectral peak identification algorithm based on continuous wavelet transform combined with particle swarm optimization (PSO) and maximum interclass variance method (Otsu) was proposed to achieve accurate, efficient and automated identification of C4D signal peaks. Capillary electrophoresis (CE) combined with a C4D device (CE-C4D) was used to detect the standard ions and soil sample solutions to obtain the C4D ion signal spectra, which were simulated according to the characteristics of the real C4D signal spectra to obtain the C4D simulated signals containing single Gaussian peaks and multi-Gaussian peaks. The continuous wavelet transform was performed on the C4D spectrogram signal to obtain the wavelet transform coefficient matrix. The local maxima and local minima of the continuous wavelet transform coefficient matrix were searched by the staircase scanning method, and the local maxima and local minima were connected to form ridges and valleys. The wavelet coefficient matrix was converted to a gray-scale image by logistic mapping to visualize the data. The number of particle populations in PSO was set to 15, the gray scale threshold of 15 particles was set to a random integer within the gray scale level of 0~255, and the initial velocity of the particles was set to 5. The combination of PSO and Otsu calculated the fitness (variance value) of each particle, updated the individual best position and the global best position, further updated the velocities and positions of the particles to find the global best position (the maximum interclass variance), and defined the maximum interclass variance was defined as the optimal threshold value, used the optimal threshold value for background and target segmentation of the gray-scale image and extracted the ridges within the peak region segmented from the gray-scale image by the PSO-Otsu algorithm. A threshold was set according to the length of the ridge line; the ridge lines larger than the threshold were extracted; the valley lines on both sides of the ridge line were found according to the filtered ridge line; and the start and end points of the peak region were obtained from the valley lines. The filtered ridge lines were used to identify the peak location of the peak region, and the edge threshold was set to remove the false peaks due to continuous wavelet transform (CWT) located in the edge region of the C4D signal and to accurately identify the location of the true peak value. Results and Discussions The datasets containing 41, 61 and 102 peaks were tested, and the Receiver Operating Characteristic (ROC) curves and metric values were used as a guideline to evaluate the performance of the peak detection algorithms. Compared to the two methods, multi scale peak detection (MSPD) and CWT-based image segmentation (CWT-IS), the CWT combined with Particle Swarm Optimization based maximum spectral peaks automatic identification algorithm based on Continuous Wavelet Transform combined with Particle Swarm Optimization of Otsu to segment image (CWTSPSO) method of interclass variance segmentation (CWT-IS), the ROC curves of the three groups remained above 0.9. Testing the dataset containing 102 peaks, the ROC curves of MSPD and CWT-IS were also high only in the case of high false discovery rate. The highest metric values of CWTSPSO were 0.976, 0.915, and 0.969, respectively, and the highest metric values of 1 set of MSPD and CWT-IS were 0.754 and 0.505. The results showed that the ROC curves of CWTSPSO in the 3 sets of dataset were not high. Using ROC curves and metric values as a criterion comparison to evaluate the performance of peak detection algorithms, the characteristic peak recognition performance was outstanding, which could achieve a higher correct rate while maintaining a lower false discovery rate, effectively detected more weak and overlapping peaks while detecting fewer false peaks, which was conducive to the enhancement of the spectral peak recognition rate and accuracy of the C4D signals. Conclusions This study provided a fast and accurate method for the identification of characteristic peaks in the spectrograms of ion signals detected by contactless conductivity, CWTSPSO could accurately identify the weak and overlapping peaks in the spectrograms of ion signals detected by contactless conductivity. The automatic identification algorithm of the spectrogram peaks of CWTSPSO would provide powerful support for the characterization and quantification of the signals of nutrient ions detected by contactless conductivity in agricultural soils and would further strengthen the precision of soil fertilization and crop growth management fertilization and crop growth management.

Research Progresses of Crop Growth Monitoring Based on Synthetic Aperture Radar Data | Open Access
HONG Yujiao, ZHANG Shuo, LI Li
2024, 6(1):  46-62.  doi:10.12133/j.smartag.SA202308019
Asbtract ( 50 )   HTML ( 12)   PDF (1147KB) ( 71 )
Figures and Tables | References | Related Articles | Metrics

Significance Crop production is related to national food security, economic development and social stability, so timely information on the growth of major crops is of great significance for strengthening the crop production management and ensuring food security. The traditional crop growth monitoring mainly judges the growth of crops by manually observing the shape, color and other appearance characteristics of crops through the external industry, which has better reliability and authenticity, but it will consume a lot of manpower, is inefficient and difficult to carry out monitoring of a large area. With the development of space technology, satellite remote sensing technology provides an opportunity for large area crop growth monitoring. However, the acquisition of optical remote sensing data is often limited by the weather during the peak crop growth season when rain and heat coincide. Synthetic aperture radar (SAR) compensates well for the shortcomings of optical remote sensing, and has a wide demand and great potential for application in crop growth monitoring. However, the current research on crop growth monitoring using SAR data is still relatively small and lacks systematic sorting and summarization. In this paper, the research progress of SAR inversion of crop growth parameters were summarized through comprehensive analysis of existing literature, clarify the main technical methods and application of SAR monitoring of crop growth, and explore the existing problems and look forward to its future research direction. Progress] The current research status of SAR crop growth monitoring were reviewed, the application of SAR technology had gone through several development stages: from the early single-polarization, single-band stage, gradually evolving to the mid-term multi-polarization, multi-band stage, and then to the stage of joint application of tight polarization and optical remote sensing. Then, the research progress and milestone achievements of crop growth monitoring based on SAR data were summarized in three aspects, namely, crop growth SAR remote sensing monitoring indexes, crop growth SAR remote sensing monitoring data and crop growth SAR remote sensing monitoring methods. First, the key parameters of crop growth were summarized, and the crop growth monitoring indexes were divided into morphological indicators, physiological and biochemical indicators, yield indicators and stress indicators. Secondly, the core principle of SAR monitoring of crop growth parameters was introduced, which was based on the interaction between SAR signals and vegetation, and then the specific scattering model and inversion algorithm were used to estimate the crop growth parameters. Then, a detailed summary and analysis of the radar indicators mainly applied to crop growth monitoring were also presented. Finally, SAR remote sensing methods for crop growth monitoring, including mechanistic modeling, empirical modeling, semi-empirical modeling, direct monitoring, and assimilation monitoring of crop growth models, were described, and their applicability and applications in growth monitoring were analyzed. Conclusions and Prospects Four challenges exist in SAR crop growth monitoring are proposed: 1) Compared with the methods of crop growth monitoring using optical remote sensing data, the methods of crop growth monitoring using SAR data are obviously relatively small. The reason may be that SAR remote sensing itself has some inherent shortcomings; 2) Insufficient mining of microwave scattering characteristics, at present, a large number of studies have applied the backward scattering intensity and polarization characteristics to crop growth monitoring, but few have applied the phase information to crop growth monitoring, especially the application study of polarization decomposition parameters to growth monitoring. The research on the application of polarization decomposition parameter to crop growth monitoring is still to be deepened; 3) Compared with the optical vegetation index, the radar vegetation index applied to crop growth monitoring is relatively less; 4 ) Crop growth monitoring based on SAR scattered intensity is mainly based on an empirical model, which is difficult to be extended to different regions and types of crops, and the existence of this limitation prevents the SAR scattering intensity-based technology from effectively realizing its potential in crop growth monitoring. Finally, future research should focus on mining microwave scattering features, utilizing SAR polarization decomposition parameters, developing and optimizing radar vegetation indices, and deepening scattering models for crop growth monitoring.

Imaging System for Plant Photosynthetic Phenotypes Incorporating Three-dimensional Structured Light and Chlorophyll Fluorescence | Open Access
SHU Hongwei, WANG Yuwei, RAO Yuan, ZHU Haojie, HOU Wenhui, WANG Tan
2024, 6(1):  63-75.  doi:10.12133/j.smartag.SA202311018
Asbtract ( 44 )   HTML ( 6)   PDF (1819KB) ( 41 )
Figures and Tables | References | Related Articles | Metrics

Objective The investigation of plant photosynthetic phenotypes is essential for unlocking insights into plant physiological characteristics and dissecting morphological traits. However, traditional two-dimensional chlorophyll fluorescence imaging methods struggle to capture the complex three-dimensional spatial variations inherent in plant photosynthetic processes. To boost the efficacy of plant phenotyping and meet the increasingly demand for high-throughput analysis of photosynthetic phenotypes, the development and validation of a novel plant photosynthetic phenotype imaging system was explored, which uniquely combines three-dimensional structured light techniques with chlorophyll fluorescence technology. Methods The plant photosynthetic phenotype imaging system was composed of three primary parts: A tailored light source and projector, a camera, and a motorized filter wheel fitted with filters of various bandwidths, in addition to a terminal unit equipped with a development board and a touchscreen interface. The system was based on the principles and unique characteristics of chlorophyll fluorescence and structured light phase-shifted streak 3D reconstruction techniques. It utilized the custom-designed light source and projector, together with the camera's capability to choose specific wavelength bands, to its full potential. The system employed low-intensity white light within the 400–700 nm spectrum to elicit stable fluorescence, with blue light in the 440–450 nm range optimally triggering the fluorescence response. A projector was used to project dual-frequency, twelve-step phase-shifted stripes onto the plant, enabling the capture of both planar and stripe images, which were essential for the reconstruction of the plant's three-dimensional structure. An motorized filter wheel containing filters for red, green, blue, and near-infrared light, augmented by a filter less wheel for camera collaboration, facilitated the collection of images of plants at different wavelengths under varying lighting conditions. When illuminated with white light, filters corresponding to the red, green, and blue bands were applied to capture multiband images, resulting in color photographs that provides a comprehensive documentation of the plant's visual features. Upon exposure to blue light, the near-infrared filter was employed to capture near-infrared images, yielding data on chlorophyll fluorescence intensity. During the structured light streak projection, no filter was applied to obtain both planar and streak images of the plant, which were then employed in the 3D morphological reconstruction of the plant. The terminal, incorporating a development board and a touch screen, served as the control hub for the data acquisition and subsequent image processing within the plant photosynthetic phenotypic imaging system. It enabled the switching of light sources and the selection of camera bands through a combination of command and serial port control circuits. Following image acquisition, the data were transmitted back to the development board for analysis, processing, storage, and presentation. To validate the accuracy of 3D reconstruction and the reliability of photosynthetic efficiency assessments by the system, a prototype of the plant photosynthetic phenotypic imaging system was developed using 3D structured light and chlorophyll fluorescence technology, in accordance with the aforementioned methods, serving as an experimental validation platform. The accuracy of 3D reconstruction and the effectiveness of photosynthetic analysis capabilities of this imaging system were further confirmed through the analysis and processing of the experimental results, with comparative evaluations conducted against conventional 3D reconstruction methods and traditional chlorophyll fluorescence-based photosynthetic efficiency analyses. Results and Discussions The imaging system utilized for plant photosynthetic phenotypes incorporates a dual-frequency phase-shift algorithm to facilitate the reconstruction of three-dimensional (3D) plant phenotypes. Simultaneously, plant chlorophyll fluorescence images were employed to evaluate the plant's photosynthetic efficiency. This method enabled the analysis of the distribution of photosynthetic efficiency within a 3D space, offering a significant advancement over traditional plant photosynthetic imaging techniques. The 3D phenotype reconstructed using this method exhibits high precision, with an overall reconstruction accuracy of 96.69%. The total error was merely 3.31%, and the time required for 3D reconstruction was only 1.11 s. A comprehensive comparison of the 3D reconstruction approach presented with conventional methods had validated the accuracy of this technique, laying a robust foundation for the precise estimation of a plant's 3D photosynthetic efficiency. In the realm of photosynthetic efficiency analysis, the correlation coefficient between the photosynthetic efficiency values inferred from the chlorophyll fluorescence image analysis and those determined by conventional analysis exceeded 0.9. The experimental findings suggest a significant correlation between the photosynthetic efficiency values obtained using the proposed method and those from traditional methods, which could be characterized by a linear relationship, thereby providing a basis for more precise predictions of plant photosynthetic efficiency. Conclusions The method melds the 3D phenotype of plants with an analysis of photosynthetic efficiency, allowing for a more holistic assessment of the spatial heterogeneity in photosynthetic efficiency among plants by examining the pseudo-color images of chlorophyll fluorescence's spatial distribution. This approach elucidates the discrepancies in photosynthetic efficiency across various regions. The plant photosynthetic phenotype imaging system affords an intuitive and comprehensive view of the photosynthetic efficiency in plants under diverse stress conditions. Additionally, It provides technical support for the analysis of the spatial heterogeneity of high-throughput photosynthetic efficiency in plants.

Electrochemical Immunosensor for in Situ Detection of Brassinolide | Open Access
WEI Qian, GAO Yuanyuan, LI Aixue
2024, 6(1):  76-88.  doi:10.12133/j.smartag.SA202311001
Asbtract ( 23 )   HTML ( 2)   PDF (1903KB) ( 33 )
Figures and Tables | References | Related Articles | Metrics

Objective Brassinolide is an important endogenous plant hormone. In this work, an electrochemical immunosensor for in situ detection of brassinolide was constructed using screen-printed electrode (SPE). Methods Au nanoparticles (AuNPs) were firstly electrodeposited on the surface of SPE electrode by electrochemical workstation, and then CuCl2 nanowires (CuCl2 NWs) were added to the electrode, which can not only increase the conductivity of the electrode, but also Cu2+ can be used as a REDOX probe for the sensor. Finally, Mxene and polydopamine nanocomposite (Mxene@PDA) were selected as the modification materials for SPE electrodes because Mxene has the advantages of large surface area and good electrical conductivity, which can further amplify Cu2+ signals. However, Mxene is easily oxidized and unstable in air. Polydopamine (PDA) contains a large number of catechol and amino groups, which are coated on the surface of Mxene after self-polymerization by dopamine, cutting off the path of oxygen penetration, making Mxene difficult to be oxidized. Mxene@PDA can also be used as a coupling agent to fix more antibodies on the electrode surface, improving the overall biocompatibility, and improve the overall biocompatibility. Results and Discussions The sensor has a wide linear detection range: 0.1 pg/mL to 1 mg/mL, and the detection limit was 0.015 pg/ml (S/N=3). In addition, the content of endogenous brassinolide in wheat was detected by SPE electrodes in vitro and the recovery rate was 98.13% to 104.74%.While verifying the accuracy of the sensor, it also demonstrated its superior stability and sensitivity. Besides, the sensor also showed excellent application potential in the in situ detection of brassinosteroids from wheat leaves. Compared with other brassinolide detection methods, the immunosensor developed in this study has better analytical performance. Conclusions An electrochemical immunosensor for in situ detection of brassinolide was developed for the first time, providing a good electrochemical platform for in situ determination of brassinolide in plant leaves, which has great application potential in precision agriculture.

Using a Portable Visible-near Infrared Spectrometer and Machine Learning to Distinguish and Quantify Mold Contamination in Wheat | Open Access
JIA Wenshen, LYU Haolin, ZHANG Shang, QIN Yingdong, ZHOU Wei
2024, 6(1):  89-100.  doi:10.12133/j.smartag.SA202311032
Asbtract ( 26 )   HTML ( 2)   PDF (2050KB) ( 26 )
Figures and Tables | References | Related Articles | Metrics

Objective Traditional methods for detecting mold are time-consuming, labor-intensive, and vulnerable to environmental influences, highlighting the need for a swift, precise, and dependable detection approach. Researchers have utilized visible-near infrared (NIR) spectroscopy for the non-destructive, rapid assessment of wheat moisture content, crude protein content, concealed pests, starch content, dry matter, weight, hardness, origin, and other attributes. However, most of these studies rely on research-grade Visible-NIR spectrometers typically found in laboratories. While these spectrometers offer superior detection accuracy and stability, their bulky size, lack of portability, and high cost hinder their widespread use and adoption across various agricultural product distribution channels. Methods A low-resolution Visible-NIR spectrometer (VNIAPD, with a resolution of 1.6 nm) was utilized to gather wheat data. The aim was to enhance the accuracy of moldy wheat detection by identifying suitable spectral data preprocessing methods using corresponding algorithms. A high-resolution Visible-NIR spectrometer (SINO2040, with a resolution of 0.19 nm) served as a control to validate the instrument and method's effectiveness. The Zhoumai (No. 22) wheat variety was adopted, with a total of 100 samples prepared. The spectra of fresh wheat were scanned and then placed in a constant temperature chamber at 35 °C to replicate the appropriate conditions for mold growth, thereby accelerating the reproduction of naturally occurring mold in the wheat. The degree of mold was categorized based on the cultivation time in the constant temperature chamber, with wheat classified as mildly, moderately, or severely moldy after 3, 6, and 9 days of cultivation, respectively. A total of 400 wheat spectral data points were collected, including 100 samples each of fresh wheat, wheat cultured for 3 days, wheat cultured for 6 days, and wheat cultured for 9 days. Preprocessing methods such as standard deviation normalization (SDN), standard normal variation (SNV), mean centrality (MC), first-order derivatives (1ST), Savitzky-Golay smoothing (SG), and multiple scattering correction (MSC) were applied to the spectral data. Outliers were identified and eliminated using the local outlier factor (LOF) method. Following this, the sequential projection algorithm (SPA) and Least absolute shrinkage and selection operator (LASSO) were used to extract characteristic wavelengths from the preprocessed spectra. Subsequently, six algorithms, including k-nearest neighbors (KNN), support vector machines (SVM), random forests (RF), Naïve-Bayes, back propagation neural networks (BPNN), and deep neural networks (DNN), were employed to model and analyze the feature wavelength spectra, differentiating moldy wheat and classifying the degree of mold. Evaluation criteria encompassed accuracy, modeling time, and model size to aid in selecting the most suitable model for specific application scenarios. Results and discussions Regarding accuracy, even when utilizing the computationally slower and more memory-demanding neural network models BPNN and DNN, both the VNIAPD and SINO2040 achieved a perfect 100% accuracy in the binary classification task of distinguishing between fresh and moldy wheat. They also maintained a faultless 100% accuracy in the ternary classification task that differentiates three varying levels of mold growth. Adopting faster and more memory-efficient shallow models such as KNN, SVM, RF, and Naïve-Bayes, the VNIAPD yielded a top test set accuracy of 97.72% when combined with RF for binary classification. Conversely, SINO2040 achieved 100% accuracy using Naïve-Bayes. In the ternary classification scenario, the VNIAPD hit the mark at 100% accuracy with both KNN and RF, while SINO2040 demonstrated 97.72% accuracy with KNN and SVM. Regarding modeling speed, the shallow machine learning algorithms, including KNN, SVM, RF, and Naïve-Bayes, exhibited quicker training times, with Naïve-Bayes being the swiftest at just 3 ms. In contrast, the neural network algorithms BPNN and DNN required more time for training, taking 3 293 and 18 614 ms, respectively. Regarding memory footprint, BPNN had the largest model size, occupying 4 028 kb, whereas SVM was the most memory-efficient, with a size of only 4 kb. Overall, the VNIAPD matched the SINO2040 in detection accuracy despite having lower optical parameters: A slightly lesser optical resolution of 1.6 nm compared to the SINO2040's 0.19 nm—and a lower cost, highlighting its efficiency and cost-effectiveness in the given context. Conclusions In this study, by comparing different preprocessing methods for spectral data, the optimal data optimization choices for corresponding algorithms were identified. As a result, the low-resolution spectrometer VNIAPD was able to achieve performance on par with the high-resolution spectrometer SINO2040 in detecting moldy wheat, providing a new option for low-cost, non-destructive detection of wheat mold and the degree of moldiness based on Visible-NIR spectroscopy.

AgNPs Prepared by Lemon Juice Reduction Method for SERS Rapid Detection of Pesticide Residues in Fruits and Vegetables | Open Access
DONG Shanshan, ZHANG Fengqiu, XIA Qi, LI Jialin, LIU Chao, LIU Shaowei, CHEN Xiangyu, WANG Rujing, HUANG Qing
2024, 6(1):  101-110.  doi:10.12133/j.smartag.SA202311010
Asbtract ( 14 )   HTML ( 1)   PDF (2305KB) ( 5 )
Figures and Tables | References | Related Articles | Metrics

Objective The use of pesticides is one of the root causes of food safety problems. Pesticide exposure and pesticide residues can not only lead to environmental pollution issues but also seriously affect human health. In order to meet the rapid and sensitive detection needs of pesticide residues in agricultural products, a method based on lemon juice reduction to prepare silver nanoparticles (AgNPs) is reported in this research. Methods First, fresh lemon juice was filtered through filter paper and diluted to a 2% lemon juice aqueous solution. Then, a certain concentration of AgNO3 solution, 50 mm NaOH solution were prepared and stored at room temperature. Then, 10 mL ddH2O, 2 mL NaOH, 2 mL 2% lemon juice, and 5 mL AgNO3 solution were mixed. When the solution turned to a clear yellow color, the solution was centrifuged to obtain AgNPs. The morphology and structure of AgNPs were observed by transmission electron microscopy (TEM). In order to verify the successful synthesis of the nanoparticles and the distribution characteristics of the nanoparticles, ultraviolet spectroscopy was used for measurement and analysis, and 4-ATP was used as a SERS probe to preliminarily verify the SERS enhancement performance of AgNPs. Furthermore, the content of the main reducing components in lemon juice, namely ascorbic acid, glucose, and fructose was analyzed. The content of ascorbic acid in lemon juice was determined by high-performance liquid chromatography, and the content of glucose and fructose in lemon juice was determined by UV-visible spectrophotometry. To verify the stability and uniformity of the SERS signal of the nanoparticles, 4-ATP was used as an surface enhancement of raman scattering (SERS) probe for detection analysis. The stability of the SERS performance of the colloidal substrate within 41 days and the SERS performance at temperatures ranging from 0-80 °C were analyzed. Using 4-ATP as the SERS probe, the experimental conditions were optimized for the preparation of AgNPs by the lemon juice method, including pH and AgNO3 concentration. To validate the practical usability of the nanoparticles, the solutions of paraquat and carbendazim and the detection limits of pesticide residues on different fruits and vegetables were detected by SERS. Results and discussions The method for preparing AgNPs has the advantages of simple operation, green and easy synthesis. The particle morphology and size of the prepared AgNPs were basically uniform, with a size of about 20 nm. The ultraviolet-visible spectrum of AgNPs solution showed that the absorption peak was about 400 nm and the peak shape was narrow, indicating that the colloidal solution had good homogeneity. The detection limit of 4-ATP as the SERS probe was 10-14 M, indicating that the nanoparticle had a good SERS. In addition, the content of ascorbic acid, the main reducing ingredient, in lemon juice measured by high-performance liquid chromatography (HPLC) was 395.76 μg/mL. The contents of glucose and fructose, which were the main reducing components in lemon juice, were 5.95 and 5.90 mg/mL, respectively. Furthermore, the characterization and analysis results of the AgNPs prepared by the mixed reducing solution prepared according to the concentration data of each component showed that the AgNPs obtained were also uniform in morphology and size, with a diameter of about 20 nm, but the SERS enhancement performance was not as good as that of the AgNPs reduced by lemon juice. The SERS signal uniformity of the AgNPs reduced by lemon juice analyzed results showed that the peak intensity of the SERS spectral of 4-ATP at different sites at the same concentration was not significantly changed for 15 times, and its standard deviation RSD=5.03%, which was much lower than the intersubstrate RSD value (<16%) of the qualified new SERS active substrate for quantitative analysis. The temporal stability and temperature stability of AgNPs analyzed results showed that the nanoparticles still had SERS enhanced performance after 41 days of storage, and had SERS enhanced performance stability over a wide temperature range (0~80 °C). In addition, the optimization results of experimental conditions showed that the optimal pH for the preparation of AgNPs was around 7.5, and the optimal range of AgNO3 concentration used was 1.76×10-4~3.33×10-4 mol/L. Finally, using AgNPs prepared by lemon juice reduction method for pesticide residue SERS detection on the surface of fruits and vegetables, the detection limits for paraquat and carbendazim in solution were as low as 10-14 and 10-10 M, respectively, and the concentration of pesticides showed a good linear relationship with Raman spectral intensity. The lowest detection limits for paraquat and carbendazim residues on different fruits and vegetables were as low as 3.90 ng/kg and 0.22 µg/kg, respectively. Conclusions This work provides a green and convenient method for preparing SERS materials for rapid detection of pesticide residues on fruits and vegetables. This method has practical value for universal operation. The prepared AgNPs can be used for trace pesticide residue detection, providing a pathway for rapid and sensitive detection of pesticide residues in agricultural products.

Intelligent Detection and Alarm System for Ferrous Metal Foreign Objects in Silage Machines | Open Access
ZHANG Qing, LI Yang, YOU Yong, WANG Decheng, HUI Yunting
2024, 6(1):  111-122.  doi:10.12133/j.smartag.SA202306010
Asbtract ( 44 )   HTML ( 6)   PDF (2026KB) ( 45 )
Figures and Tables | References | Related Articles | Metrics

Objective During the operation of the silage machine, the inclusion of ferrous metal foreign objects such as stray iron wires can inflict severe damage to the machine's critical components and livestock organs. To safeguard against that, a metal detection system with superior performance was developed in this research to enable precise and efficient identification of metal foreign bodies during field operations, ensuring the integrity of the silage process and the well-being of the animals. Methods The ferrous metal detection principle of silage machine was firstly analyzed. The detection coil is the probe of the metal detection system. After being connected in parallel with a capacitor, it is connected to the detection module. The detection coil received the alternating signal generated by the detection module to generate an alternating magnetic field. After the metal object entered the magnetic field, it affects the equivalent resistance and equivalent inductance of the detection coil. The detection module detected the change of the equivalent resistance and equivalent inductance, and then transmited the signal to the control module through the serial peripheral interface (SPI). The control module filtered the signal and transmited it to the display terminal through the serial port. The display terminal could set the threshold. When the data exceeded the threshold, the system performed sound and light alarm and other processing. Hardware part of the metal detection system of silage machine were firstly design. The calculation of the planar spiral coil and the cylindrical coil was carried out and the planar spiral coil was selected as the research object. By using the nondominated sorting genetic algorithm-Ⅱ (NSGA-II) combined with the method of finite element simulation analysis, the wire diameter, inner diameter, outer diameter, layer number and frequency of the coil were determined, and the calculation of the bent coil and the unbent coil and the array coil was carried out. The hardware system was integrated. The software system for the metal detection system was also designed, utilizing an STM32 microcontroller as the control module and LabView for writing the primary program on the upper computer. The system continuously displayed the read data and time-equivalent impedance graph in real-time, allowing for the setting of upper and lower alarm thresholds. When a metal foreign object was detected, the warning light turned red and an alarm sound was emitted, causing the feed roll to stop. To simulate the scenario of metal detection during the operation of a silage machine, a test bench was set up to validate the performance of the metal detection system. Results and Discussions The test results of the metal detection function showed that for a metal wire with a diameter of 0.6 mm and a length of 20 mm, as the inner diameter of the detection coil increased, the maximum alarm distance increased first and then decreased. The maximum alarm distance occured when the inner diameter was 35 mm, which was consistent with the optimization result. The maximum alarm distance was the largest when the detection coil was two layers, and there was no data readout when it was three layers. Therefore, the optimal thickness of the detection coil for this metal detection system was two layers. When the detection distance was greater than 80 mm, the alarm rate began to decrease, and the detection effect was weakened. When the detection distance was within 70 mm, the metal detection system could achieve a 100% alarm rate. The test results of the system response time showed that the average system response time was 0.105 0 s, which was less than the safe transportation time of 0.202 0 s. The system can give an alarm before the metal foreign object reaches the cutter, so the system is safe and effective. Conclusion In this study, a metal detection system for silage machines was designed. A set of optimization methods for metal detection coils was proposed, and the corresponding metal detection software and hardware systems were developed, and the functions of the metal detection system were verified through experiments, which could provide strong technical support for the safe operation of silage machines.

Information Processing and Decision Making
Agricultural Knowledge Recommendation Model Integrating Time Perception and Context Filtering | Open Access
WANG Pengzhe, ZHU Huaji, MIAO Yisheng, LIU Chang, WU Huarui
2024, 6(1):  123-134.  doi:10.12133/j.smartag.SA202312012
Asbtract ( 36 )   HTML ( 7)   PDF (1503KB) ( 43 )
Figures and Tables | References | Related Articles | Metrics

Objective Knowledge services in agricultural scenarios have the characteristics of long periodicity and prolonged activity time. Traditional recommendation models cannot effectively mine hidden information in agricultural scenarios, in order to improve the quality of agricultural knowledge recommendation services, agricultural contextual information based on agricultural time should be fully considered. To address these issues, a Time-aware and filter-enhanced sequential recommendation model for agricultural knowledge (TiFSA) was proposed, integrating temporal perception and enhanced filtering. Methods First, based on the temporal positional embedding, combining the temporal information of farmers' interactions with positional embedding based on time perception, it helped to learn project relevance based on agricultural season in agricultural contexts. A multi-head self-attention network recommendation algorithm based on time-awareness was proposed for the agricultural knowledge recommendation task, which extracted different interaction time information in the user interaction sequence and introduced it into the multi-head self-attention network to calculate the attention weight, which encoded the user's periodic interaction information based on the agricultural time, and also effectively captured the user's dynamic preference information over time. Then, through the temporal positional embedding, a filter filtering algorithm was introduced to adaptively attenuate the noise in farmers' situational data adaptively. The filtering algorithm was introduced to enhance the filtering module to effectively filter the noisy information in the agricultural dataset and alleviate the overfitting problem due to the poorly normalized and sparse agricultural dataset. By endowing the model with lower time complexity and adaptive noise attenuation capability. The applicability of this method in agricultural scenarios was improved. Next, a multi-head self attention network with temporal information was constructed to achieve unified modeling of time, projects, and features, and represent farmers' preferences of farmers over time in context, thereby providing reliable recommendation results for users. Finally, the AdamW optimizer was used to update and compute the model parameters. AdamW added L2 regularization and an appropriate penalty mechanism for larger weights, which could update all weights more smoothly and alleviate the problem of falling into local minima. Applied in the field of agricultural recommendation, it could further improve the training effect of the model. The experimental data came from user likes, comments, and corresponding time information in the "National Agricultural Knowledge Intelligent Service Cloud Platform", and the dataset ml-1m in the movie recommendation scenario was selected as an auxiliary validation of the performance of this model. Results and Discussions According to the user interaction sequence datasets in the "National Agricultural Knowledge Intelligent Service Cloud Platform", from the experimental results, it could be learned that TiFSA outperforms the other models on two different datasets, in which the enhancement was more obvious on the Agriculture dataset, where HR and NDCG were improved by 14.02% and 16.19%, respectively, compared to the suboptimal model, TiSASRec; while on the ml-1m dataset compared to the suboptimal model, SASRec, HR and NDCG were improved by 1.90% and 2.30%, respectively. In summary, the TiFSA model proposed in this paper has a large improvement compared with other models, which verifies verified the effectiveness of the TiFSA model and showed that the time interval information of farmer interaction and the filtering algorithm play an important role in the improvement of the model performance in the agricultural context. From the results of the ablation experiments, it could be seen that when the time-aware and enhanced filtering modules were removed, the values of the two metrics HR@10 and NDCG@10 were 0.293 6 and 0.203 9, respectively, and the recommended performance was poor. When only the time-aware module and only the augmentation filtering module were removed, the experimental results had different degrees of improvement compared to TiFSA-tf, and the TiFSA model proposed in this paper achieved the optimal performance in the two evaluation metrics. When only the multi-head self-attention network was utilized for recommendation, both recommendation metrics of the model were lower, indicating that the traditional sequence recommendation method that only considered the item number was not applicable to agricultural scenarios. When the augmented filtering module was introduced without the time-aware module, the model performance was improved, but still failed to achieve the ideal recommendation effect. When only the time-aware module was introduced without the augmented filtering module, there was a significant improvement in the model effect, which proved that the time-aware module was more applicable to agricultural scenarios and can effectively improve the model performance of the sequence recommendation task. When both time-aware and augmented filtering modules were introduced, the model performance was further improved, which on the one hand illustrated the dependence of the augmented filtering module on the time-aware module, and on the other hand verified the necessity of adopting the augmented filtering to the time-aware self-attention network model. Conclusions This research proposes an agricultural knowledge recommendation model that integrates time-awareness and augmented filtering, which introduces the user's interaction time interval into the embedded information, so that the model effectively learns the information of agricultural time in the agricultural scene, and the prediction of the user's interaction time and the object is more closely related to the actual scene; augmented filtering algorithms are used to attenuate the noise in the agricultural data. At the same time, the enhanced filtering algorithm is used to attenuate the noise in the agricultural data, and can be effectively integrated into the model for use, further improving the recommendation performance of the model. The experimental results show the effectiveness of the proposed TiFSA model on the agricultural dataset. The ablation experiments confirm the positive effect of time-awareness and enhanced filtering modules on the improvement of recommendation performance.

Automated Flax Seeds Testing Methods Based on Machine Vision | Open Access
MAO Yongwen, HAN Junying, LIU Chengzhong
2024, 6(1):  135-146.  doi:10.12133/j.smartag.SA202309011
Asbtract ( 53 )   HTML ( 34)   PDF (1671KB) ( 869 )
Figures and Tables | References | Related Articles | Metrics

Objective Flax, characterized by its short growth cycle and strong adaptability, is one of the major cash crops in northern China. Due to its versatile uses and unique quality, it holds a significant position in China's oil and fiber crops. The quality of flax seeds directly affects the yield of the flax plant. Seed evaluation is a crucial step in the breeding process of flax. Common parameters used in the seed evaluation process of flax include circumference, area, length axis, and 1 000-seed weight. To ensure the high-quality production of flax crops, it is of great significance to understand the phenotypic characteristics of flax seeds, select different resources as parents based on breeding objectives, and adopt other methods for the breeding, cultivation, and evaluation of seed quality and traits of flax. Methods In response to the high error rates and low efficiency issues observed during the automated seed testing of flax seeds, the measurement methods were explored of flax seed contours based on machine vision research. The flax seed images were preprocessed, and the collected color images were converted to grayscale. A filtering and smoothing process was applied to obtain binary images. To address the issues of flax seed overlap and adhesion, a contour fitting image segmentation method based on fused corner features was proposed. This method incorporated adaptive threshold selection during edge detection of the image contour. Only multi-seed target areas that met certain criteria were subjected to image segmentation processing, while single-seed areas bypassed this step and were directly summarized for seed testing data. After obtaining the multi-seed adhesion target areas, the flax seeds underwent contour approximation, corner extraction, and contour fitting. Based on the provided image contour information, the image contour shape was approximated to another contour shape with fewer vertices, and the original contour curve was simplified to a more regular and compact line segment or polygon, minimizing computational complexity. All line shape characteristics in the image were marked as much as possible. Since the pixel intensity variations in different directions of image corners were significant, the second derivative matrix based on pixel grayscale values was used to detect image corners. Based on the contour approximation algorithm, contour corner detection was performed to obtain the coordinates of each corner. The resulting contour points and corners were used as outputs to further improve the accuracy and precision of subsequent contour fitting methods, resulting in a two-dimensional discrete point dataset of the image contour. Using the contour point dataset as an input, the geometric moments of the image contour were calculated, and the optimal solution for the ellipse parameters was obtained through numerical optimization based on the least squares method and the geometric features of the ellipse shape. Ultimately, the optimal contour was fitted to the given image, achieving the segmentation and counting of flax seed images. Meanwhile, each pixel in the digital image was a uniform small square in size and shape, so the circumference, area, and major and minor axes of the flax seeds could be represented by the total number of pixels occupied by the seeds in the image. The weight of a single seed could be calculated by dividing the total weight of the seeds by the total number of seeds detected by the contour, thereby obtaining the weight of the individual seed and converting it accordingly. Through the pixelization of the 1 yuan and 1 jiao coins from the fifth iteration of the 2019 Renminbi, a summary of the circumference, area, major axis, minor axis, and 1 000-seed weight of the flax seeds was achieved. Additionally, based on the aforementioned method, this study designed an automated real-time analysis system for flax seed testing data, realizing the automation of flax seed testing research. Experiments were conducted on images of flax seeds captured by an industrial camera. Results and Discussions The proposed automated seed identification method achieved an accuracy rate of 97.28% for statistically distinguishing different varieties of flax seeds. The average processing time for 100 seeds was 69.58 ms. Compared to the extreme erosion algorithm and the watershed algorithm based on distance transformation, the proposed method improved the average calculation accuracy by 19.6% over the extreme erosion algorithm and required a shorter average computation time than the direct use of the watershed algorithm. Considering the practical needs of automated seed identification, this method did not employ methods such as dilation or erosion for image morphology processing, thereby preserving the original features of the image to the greatest extent possible. Additionally, the flax seed automated seed identification data real-time analysis system could process image information in batches. By executing data summarization functions, it automatically generated corresponding data table folders, storing the corresponding image data summary tables. Conclusions The proposed method exhibits superior computational accuracy and processing speed, with shorter operation time and robustness. It is highly adaptable and able to accurately acquire the morphological feature parameters of flax seeds in bulk, ensuring measurement errors remain within 10%, which could provide technical support for future flax seed evaluation and related industrial development.

Lightweighted Wheat Leaf Diseases and Pests Detection Model Based on Improved YOLOv8 | Open Access
YANG Feng, YAO Xiaotong
2024, 6(1):  147-157.  doi:10.12133/j.smartag.SA202309010
Asbtract ( 133 )   HTML ( 25)   PDF (1991KB) ( 215 )
Figures and Tables | References | Related Articles | Metrics

Objective To effectively tackle the unique attributes of wheat leaf pests and diseases in their native environment, a high-caliber and efficient pest detection model named YOLOv8-SS (You Only Look Once Version 8-SS) was proposed. This innovative model is engineered to accurately identify pests, thereby providing a solid scientific foundation for their prevention and management strategies. Methods A total of 3 639 raw datasets of images of wheat leaf pests and diseases were collected from 6 different wheat pests and diseases in various farmlands in the Yuchong County area of Gansu Province, at different periods of time, using mobile phones. This collection demonstrated the team's proficiency and commitment to advancing agricultural research. The dataset was meticulously constructed using the LabelImg software to accurately label the images with targeted pest species. To guarantee the model's superior generalization capabilities, the dataset was strategically divided into a training set and a test set in an 8:2 ratio. The dataset includes thorough observations and recordings of the wheat leaf blade's appearance, texture, color, as well as other variables that could influence these characteristics. The compiled dataset proved to be an invaluable asset for both training and validation activities. Leveraging the YOLOv8 algorithm, an enhanced lightweight convolutional neural network, ShuffleNetv2, was selected as the basis network for feature extraction from images. This was accomplished by integrating a 3×3 Depthwise Convolution (DWConv) kernel, the h-swish activation function, and a Squeeze-and-Excitation Network (SENet) attention mechanism. These enhancements streamlined the model by diminishing the parameter count and computational demands, all while sustaining high detection precision. The deployment of these sophisticated methodologies exemplified the researchers' commitment and passion for innovation. The YOLOv8 model employs the SEnet attention mechanism module within both its Backbone and Neck components, significantly reducing computational load while bolstering accuracy. This method exemplifies the model's exceptional performance, distinguishing it from other models in the domain. By integrating a dedicated small target detection layer, the model's capabilities have been augmented, enabling more efficient and precise pest and disease detection. The introduction of a new detection feature map, sized 160×160 pixels, enables the network to concentrate on identifying small-targeted pests and diseases, thereby enhancing the accuracy of pest and disease recognition. Results and Discussion The YOLOv8-SS wheat leaf pests and diseases detection model has been significantly improved to accurately detect wheat leaf pests and diseases in their natural environment. By employing the refined ShuffleNet V2 within the DarkNet-53 framework, as opposed to the conventional YOLOv8, under identical experimental settings, the model exhibited a 4.53% increase in recognition accuracy and a 4.91% improvement in F1-Score, compared to the initial model. Furthermore, the incorporation of a dedicated small target detection layer led to a subsequent rise in accuracy and F1-Scores of 2.31% and 2.16%, respectively, despite a minimal upsurge in the number of parameters and computational requirements. The integration of the SEnet attention mechanism module into the YOLOv8 model resulted in a detection accuracy rate increase of 1.85% and an F1-Score enhancement of 2.72%. Furthermore, by swapping the original neural network architecture with an enhanced ShuffleNet V2 and appending a compact object detection sublayer (namely YOLOv8-SS), the resulting model exhibited a heightened recognition accuracy of 89.41% and an F1-Score of 88.12%. The YOLOv8-SS variant substantially outperformed the standard YOLOv8, showing a remarkable enhancement of 10.11% and 9.92% in accuracy, respectively. This outcome strikingly illustrates the YOLOv8-SS's prowess in balancing speed with precision. Moreover, it achieves convergence at a more rapid pace, requiring approximately 40 training epochs, to surpass other renowned models such as Faster R-CNN, MobileNetV2, SSD, YOLOv5, YOLOX, and the original YOLOv8 in accuracy. Specifically, the YOLOv8-SS boasted an average accuracy 23.01%, 15.13%, 11%, 25.21%, 27.52%, and 10.11% greater than that of the competing models, respectively. In a head-to-head trial involving a public dataset (LWDCD 2020) and a custom-built dataset, the LWDCD 2020 dataset yielded a striking accuracy of 91.30%, outperforming the custom-built dataset by a margin of 1.89% when utilizing the same network architecture, YOLOv8-SS. The AI Challenger 2018-6 and Plant-Village-5 datasets did not perform as robustly, achieving accuracy rates of 86.90% and 86.78% respectively. The YOLOv8-SS model has shown substantial improvements in both feature extraction and learning capabilities over the original YOLOv8, particularly excelling in natural environments with intricate, unstructured backdrops. Conclusion The YOLOv8-SS model is meticulously designed to deliver unmatched recognition accuracy while consuming a minimal amount of storage space. In contrast to conventional detection models, this groundbreaking model exhibits superior detection accuracy and speed, rendering it exceedingly valuable across various applications. This breakthrough serves as an invaluable resource for cutting-edge research on crop pest and disease detection within natural environments featuring complex, unstructured backgrounds. Our method is versatile and yields significantly enhanced detection performance, all while maintaining a lean model architecture. This renders it highly appropriate for real-world scenarios involving large-scale crop pest and disease detection.
